Axim WH Series - Window Handles
Verified by manufacturer 4 months ago
Cockspur Handle
Cockspur Handle
A range of casement window handles.
Application
Casement windows.
Description
A matching suite of handles in the most popular finishes.
Cockspur handles:
Cockspur handles for open out casement windows.
- Push button, key locking.
- Either right-hand or left-hand.
- 9 mm Spur height.
- 38 x 58 mm fixing centres.
- Concealed fixing with colour matched cap.
Espagnolette handles:
Espagnolette handles for open out casement windows.
- Push button, key locking.
- Offset cranked handle either right-hand or left-hand.
- Matching handle option, straight inline non-handed.
- Concealed fixing with colour matched cap.
- Spindle lengths 10, 20 and 30 mm.
Tilt turn handle:
Turn lock handles for tilt/ turn, open in windows.
- Key locking, with three functions, fully locked, restricted tilt only mode or side hung open in.
- Non handed.
- Small rose with concealed fixing and colour matched cap.
General information
Color | Black White Silver Grey Guidance for specification option: Anthracite Other Guidance for specification option: Polished Chrome |
Finish | Polished Chrome |
Material | Aluminium Guidance for specification option: Cast Aluminium |
Warranty description | One year |
Uniclass | |
CAWS | P21/900 Casement handles P21/84 Casement window handles |
Specification data - Window latch and lock operating handles
Form | WH007ANTH Cockspur Handle 9 mm L/H.WH007BSVR Cockspur Handle 9 mm L/H.WH007DBLK Cockspur Handle 9 mm L/H.WH007EWHT Cockspur Handle 9 mm L/H.WH007PCHR Cockspur Handle 9 mm L/H.WH008ANTH Cockspur Handle 9 mm R/H.WH008BSVR Cockspur Handle 9 mm R/H.WH008DBLK Cockspur Handle 9 mm R/H.WH008EWHT Cockspur Handle 9 mm R/H.WH008PCHR Cockspur Handle 9 mm R/H. |
Colour | See 'Variant'/Product code. |
Sustainability data
Contains Red List materials | No |
Country of material origin | Taiwan |
Country of product manufacture | Taiwan |
Literature
Axim Window and Door Handles
