AT System - Dual-Function Active & Passive PVC Waterstops - Dual Function PVC Waterstop System
Verified by manufacturer 18 days ago
Servitite AT 200
Servitite AT 200
Dual function PVC waterstop system with co-extruded hydrophilic bulbs to provide a unique combination of active and passive protection for joints in concrete.
Application
Internal and external applications. For water excluding and retaining structures such as basements, reservoirs, sewage treatment works, etc.
Serviseal® AT 240:
Can be cast on the external face for water excluding structures such as basements and sub structures or ground bearing slabs only of water retaining structures.
Servitite® AT 200:
An internally placed waterstop which is cast centrally in the concrete to resist internal and external water pressure.
Description
High security Polyvinyl chloride (PVC) waterstop system with co-extruded hydrophilic bulbs to provide a distinct combination of active and passive protection for joints in concrete. The two profiles can be combined, using factory produced transition junctions where Serviseal® AT 240 is used on the base slab and Servitite AT 200 is used within walls.
Features and benefits:
- Increased Security - combines advantages of PVC waterstop with active hydrophilic elements to provide maximum resistance to water pressure.
- Continuously active sealing – hydrophilic elements swell in contact with water to plug voids formed by normal concrete shrinkage.
- Prevents water tracking – location of active element is designed to prevent lateral migration of water along waterstop bulb.
- Protective coating prevents premature swelling of hydrophilic element whilst exposed and for 12 to 18 days after casting to avoid spalling of fresh concrete.
- Easy installation.
General information
Color | Black Green Yellow |
Material | PVC Guidance for specification option: Polyvinyl chloride (PVC). |
Shape | Manufacturer guidanceAvailable in shapes and configurations to suit site requirements. |
Length | 7500 mm |
Width | 200 mm 240 mm |
Height | 18 mm 25 mm |
Warranty description | Ten year |
Uniclass | |
CAWS | E40/310 Flexible waterstops |
Specification data - Centrally placed unplasticized polyvinyl chloride (PVC-U) flexible waterstops
Classification data | |
Width | 200 mm. |
Secura clips | Small (20 mm). Guidance for specification option: To tie Servitite® AT 200 reinforcement. |
TensileStrength | >14 N/mm². |
Elongation at break | >250%. |
Shore A hardness | 80 ± 4. |
Specific gravity | 1.42. |
Sustainability data
Country of product manufacture | United Kingdom |
Material | PVC Guidance for specification option: Polyvinyl chloride (PVC). |
BIM objects
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
| Platform | Compatible | Version |
|---|---|---|
 IFC | - | 1 |
 Revit | - | 1 |
Similar products from GCP Applied Technologies
PVC Edgetie™ - Centrally Placed PVC Waterbar
