ASSA ABLOY - 3900 High Security Masterkey System
Verified by manufacturer 8 months ago
133907 - Double Rim Cylinder
133907 - Double Rim Cylinder
Range of locks with two pin side bar.
Application
Suitable for any application.
Description
The ASSA Triton² 3900 range includes a two pin side bar which offers an excellent 3.4 million combinations, complimented with a wide range of cylinder shapes and functions for any application.
General information
Color | Silver |
Finish | Chrome |
Material | Steel |
Shape | Other Manufacturer guidanceVaries by product option. |
Warranty description | Ten year |
Uniclass | |
CAWS | P21/26 Special function door locks P21/24 Door locks P21/22 Thief-resistant door locks P21/530 Special function door locks P21/515 Door locks P21/510 Thief-resistant door locks |
Specification data - Thief-resistant door locks
Classification data | |
Lock type | Cylinder rim lock. |
Cylinders | |
Standard | To BS EN 1303. |
Pattern | Rim. |
Classification grades (minimum) | |
Category of use | To BS EN 1303, grade 1. |
Durability | To BS EN 1303, grade 6. |
Door mass | To BS EN 1303, grade 0. |
Fire and smoke resistance | To BS EN 1303, grade B. |
Safety | To BS EN 1303, grade 0. |
Corrosion resistance and temperature | To BS EN 1303, grade C. |
Security | To BS EN 1303, grade 6. |
Attack resistance | To BS EN 1303, grade D when used with appropriate security escutcheon. |
Material and finish | Satin Chrome. |
Execution | Fasteners for hardware |
Additional properties | For use with ASSA Modular, Rim, Connect and Narrow Profile lock cases. Securing of Cylinder: The cylinder is fixed to the lock case with two brass screws which can be cut to length. Supplied with rim cylinder sleeve. Sleeve is not required when used with Connect 35mm backset lock cases and Narrow Profile accessories. When using narrow profile double accessories (only) specify two 3907 single outside cylinders rather than a double cylinder. Cylinder Features: Drill Protection as Standard - 5 minutes drilling resistance Enhanced plug pulling resistance Paracentric key way for resistance to picking and manipulation of system pins Bumping resistance |
Sustainability data
Contains Red List materials | No |
Country of product manufacture | Sweden |
Material | Steel |
Recyclability | Manufacturer guidanceMetals widely recycled. |
Literature
Triton2 borchure
