Arts PC Retractable Seating

Verified by manufacturer over a year ago

Hussey Seatway Ltd

Retractable nose mounted theatre chair designed specifically for use with Hussey Seatway theatre quality, retractable platform systems.

Jump to:
+44 (0)1985 847200 Website

Application

Contemporary platform chair designed for use in theatres, black box studios and conference venues.

Description

Retractable seating mounted onto a platform.


Arts PC chair:

The product features a foldable backrest which allows thicker foam to be utilized and greater contouring of both the seat pan and backrest. Predominantly supplied onto Retractable platforms for the theatres, black box studios and conference venues. The chair is also available for fixed and flat floor applications.


Seatway TP Platform:

The retractable platform system has been developed to feature a welded design leading to an Inherently stiffer structure. The platforms accommodate any of the manufacturer's bench and chair range leading to a fully integrated solution. Manufactured in the UK and certified to EN 1090.


Features and benefits:

- Seating:

  • 500 mm to 560 mm seat centres.
  • Fully contoured upholstery.
  • Automatic folding armrest.
  • Spring activated tipping with a fully enclosed silent stop mechanism.
  • Solid wood armrests as standard.
  • Designed for use on Hussey Seatway TP retractable platforms with a 244 mm to 300 mm row rise.


- Platform:

  • Distinctive fully welded platform design.
  • Adjustable cantilevers on every row to compensate for any floor deviances.
  • Parallel guidance system for straight line operation.
  • Stiff and dynamically correct under-structure with unique space frame construction methods.
  • Row to row, parallel and vertical, column interlock.
  • Non marking polyurethane wheels.


General information

Color

Black

Other

Guidance for specification option:

Fabric colour bespoke to project requirement.

Finish

Powder coated

Guidance for specification option:

Custom powder coat colours available.

Material

Steel

Fabric

Wood

Warranty description

Ten year

Guidance for specification option:

Ten year warranty, condition based.

Size

-

Manufacturer guidance

Bespoke based on project requirement. Seat centres from 460 mm.

Uniclass

Pr_40_30_29_72 Retractable seatsPrimary

CAWS

N10/172 Retractable/ demountable seating systems

Specification data - Retractable seats

Fire performance

BS 5852 Ignition Source 5.

Manufacturer guidance

The fabric and foam comply with BS 5852:1990 (Source 0, 1 and 5). Other codes or European Standards can be satisfied as required. Applies to plastic, fabric and foam.

Form

TP-F - Wall and floor-fixed.
TP-M - Mobile unit.
TP-R - Wall-fixed, recessed.
TP-T - Travelling system.

Telescopic platform

-

Unit width

-

Manufacturer guidance

Consult manufacturer and insert requirement.

Number of rows

-

Manufacturer guidance

Consult manufacturer and insert requirement.

Row depth

850 mm.
900 mm.
915 mm.
1800 mm.

Guidance for specification option:

Double depth.

Row rise

245 mm.

Guidance for specification option:

Arms.

260 mm.
280 mm.
300 mm.

Guidance for specification option:

Arms.

320 mm.

Manufacturer guidance

Custom row rises are available, contact manufacturer for details.

Seat spacing (lateral)

460 mm.
490 mm with arms.

Manufacturer guidance

From 460 mm.

Seats and backs

-

Material

Fabric from the Camira Xtreme range.

Guidance for specification option:

Customers own choice of fabric can also be specified.

Finish

-

Manufacturer guidance

Fabric available in a range of colours, consult manufacturer.

Colour

-

Manufacturer guidance

Fabric available in a range of colours, consult manufacturer.

Frames

-

Material

Steel.

Finish

Powder coated.

Guidance for specification option:

Custom powder coat colours available.

Colour

Black.

Integral accessories

Not required.
Seat numbers and row letters.
Show wood seat and back panels.
LED aisle lights.
Sponsor plaques.
Front, side and rear safety rails.
Integral power.
Fascia panel systems.
Flex rows for wheelchair spaces.
Electronic partial opening feature.

Standards

To EN 12727:2000, BS 5852:1990, BS 7176:1995, BS EN 1021 - 1 & 2:1994, BS EN 13200-5.

Centres

460 mm.

Guidance for specification option:

No arms.

490 mm.

Guidance for specification option:

Arms.

500 mm.

Guidance for specification option:

Arms.

Height

420 mm.

Guidance for specification option:

Upholstered/plastic benches.

460 mm.

Guidance for specification option:

Gallery PC & arts PC.

Width

1100 mm.

Guidance for specification option:

Aisle width.

Clearance

10 mm.

Manufacturer guidance

Between banks.

Armrest

Solid wood.

Manufacturer guidance

Colour from standard range, contact manufacturer for details.

Sustainability data

Country of product manufacture

United Kingdom
