Art + Science PVC-Free Collection: Pivot 4499V
Verified by manufacturer 27 days ago
Reform 00111
Reform 00111
Heavy commercial polyvinyl chloride (PVC)-free resilient flooring.
Application
Suitable for commercial interiors.
Recommended installation methods (product specific):
- Brick;
- Ashlar;
- Herringbone.
- Stagger.
Description
Heavy commercial polyvinyl chloride (PVC)-free resilient flooring, available in 15 colours.
Features and benefits:
- Use classification 34 Commercial Heavy to BS EN ISO 10874.
- Greenhealth approved and EPD available.
- 15-year commercial limited warranty.
- Adhesive-free installation: IOBAC MagTabs™.
- Contributes towards LEED and WELL credits.
Please note: Colour and visual variation is inherent on all modular products. Consult manufacturer's datasheet for further details.
General information
Color | Beige Grey Brown |
Finish | Other Guidance for specification option: ExoGuard+®. Woodgrain |
Material | Other Guidance for specification option: PVC-free resilient tile. |
Shape | Rectangle |
Length | 1290.1 mm |
Width | 210.1 mm |
Height | 2.5 mm |
Warranty description | 15 year |
Uniclass | |
CAWS | M50/110 Resilient floor tiling M50/10 Resilient floor tiling |
SKU Code | 4499V |
Specification data - Rubber tiles
Classification data | |
Product reference | Art + Science PVC-Free Collection: Pivot 4499V. |
Standard | To BS EN ISO 10874. |
Third-party certification | Environmental Product Declaration (EPD). |
Properties | |
Dimensions | |
Depth | 2.5 mm. |
Plan size | 1290.1 x 210.1 mm. |
Upper layer | |
Texture | Woodgrain embossed. |
Colour | Reform 00111. |
Backing layer | |
Material | Ecoworx resilient. |
Performance | |
Slip potential | |
Slip resistance value (SRV) (minimum)/ pendulum test value (PTV) (minimum) | To BS 7976-2, 58/ 52 dry/ wet. Guidance for specification option: To DIN 51130, R10. |
Level of use class | To BS EN ISO 10874, class 34. |
Surface finish | ExoGuard+®. |
Mass | 3.49 kg/m² (total mass). Guidance for specification option: Weight per box: 16.52 kg. |
FlammabilityRating | To EN 13501-1, Bfl-S1. |
Thermal resistance | To ISO 8302, 0.013 m² K/W. |
Castor chair rating | To EN 425, ISO 4918, No damage. |
Impact sound reduction | To BS EN ISO 10140, ΔLw 9 dB/ 20 dB with 2 mm underlay. |
Colour fastness | To BS EN ISO 105-BO2, 8. |
Light reflectance | 33.0. |
Dimensional stability | To EN ISO 23999, ≤0.15%. |
Sustainability data
Country of material origin | Germany |
Material | Other Guidance for specification option: PVC-free resilient tile. |
| Carbon dioxide equivalent | |
Carbon dioxide equivalent, as defined in BS EN 15804 Self-declared | |
Stage Normalised unit (kg CO₂ eq/kg) Declared unit (kg CO₂ eq/m²) Stage:A1–A3 ('Production stage') Normalised unit : Declared unit : 5.2 | |
Recyclability | Recyclable Guidance for specification option: Through our environmental guarantee, Shaw pledges to transport and recycle any Ecoworx resilient within the United States and Canada at no cost to the customer. |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 25 % |
