Armco Safety Barrier (Wall Mounted) - Wall Mounted Safety Barrier System

Armco Wall Mounted Safety Barrier

Low-Profile Impact Protection for Walls, Equipment and Infrastructure

The Armco Wall Mounted Safety Barrier is a compact, low-profile impact protection system designed to safeguard walls, equipment and infrastructure from vehicle damage in industrial and warehouse environments. Incorporating shock-absorbing rubber buffers as standard, the system reduces impact forces while maintaining a snug fit against the wall, making it ideal for areas where space is limited but protection is essential.

Designed for installation onto brick, block and pre-cast concrete walls, this barrier provides an effective and cost-efficient solution for preventing damage caused by forklifts, pallet trucks and other material handling equipment (MHE).

Designed for Low-Level Impact Protection

In industrial environments, vehicle impacts often occur at low levels, particularly from forklift forks and pallet movement. The Armco Wall Mounted Safety Barrier is engineered to intercept these impacts before they reach the building structure.

By sitting close to the wall while still providing a protective buffer, the system helps to:

• Prevent structural damage to walls and cladding
• Protect equipment mounted along wall lines
• Reduce maintenance and repair costs
• Improve overall site safety

Its low-profile design ensures protection without compromising operational space.

Built-In ImpactSAFE Shock Absorption

A key feature of this system is the integration of ImpactSAFE shock-absorbing rubber buffers, which cushion impact forces and reduce stress transferred to both the barrier and the wall structure.

This provides several advantages over standard rigid barriers:

• Reduces force transmitted to fixings and substrate
• Minimises risk of wall damage or cracking
• Improves longevity of the installation
• Enhances protection for both vehicles and infrastructure

The inclusion of shock absorption technology ensures a more controlled and effective response to vehicle impact.

Compact Design with Minimal Projection

The Armco Wall Mounted Safety Barrier offers effective protection while maintaining a minimal projection of approximately 165 mm from the wall to the front face of the barrier.

Key benefits include:

• Maintains usable floor space in tight environments
• Reduces obstruction in narrow aisles or corridors
• Improves visibility for vehicle operators
• Suitable for retrofit installations

This makes it particularly well suited to environments where traditional floor-mounted barriers are not practical.

Durable Steel and Rubber Construction

Manufactured from mild steel with integrated rubber buffers, the barrier is designed for long-term performance in demanding industrial conditions.

Material benefits include:

• High strength steel for structural durability
• Rubber buffers for impact absorption
• Suitable for internal and external use
• Resistant to wear and operational stress

The steel components can be supplied with a galvanised finish for additional corrosion resistance, ensuring consistent performance over time.

Flexible Installation for Different Risk Levels

The system can be configured based on the level of impact risk within the environment, allowing for efficient use of materials while maintaining safety.

Recommended fixing centres:

• 1.6 metre spacing – for high impact areas
• 3.2 metre spacing – for low impact areas

This flexibility allows the barrier to be tailored to site-specific conditions, balancing performance and cost.

Secure Wall-Mounted Installation

The barrier is designed for secure fixing to structural surfaces using M12 wall anchors, ensuring stability under impact conditions.

Installation details include:

• Suitable for brick, block and pre-cast concrete walls
• 14 mm diameter drill holes at 100 mm depth
• M12 x 160 mm coach screws with nylon rawl plugs
• Simple and efficient installation process

This allows for both new installations and retrofit applications across existing facilities.

Compatibility with Armco Accessories

The Armco Wall Mounted Safety Barrier can be used in conjunction with a range of Armco accessories to enhance safety and functionality.

Compatible additions include:

• Armco safety ends for covering exposed edges
• Pedestrian safety ends for improved walkway safety
• Additional handrail systems for pedestrian segregation

This enables the system to be integrated into wider safety strategies across the site.

Suitable for Industrial and Commercial Environments

The barrier is ideal for environments where wall-mounted protection is required without compromising floor space.

Typical applications include:

• Warehouses and distribution centres
• Manufacturing and production facilities
• Loading bays and service yards
• Internal traffic routes
• Equipment and machinery protection zones
• Building perimeter protection

Its versatility makes it suitable for both internal and external installations.

Operational Benefits

Installing the Armco Wall Mounted Safety Barrier provides a range of safety and operational advantages:

Protects walls and infrastructure

Prevents damage from forklift and vehicle impact.

Reduces maintenance costs

Minimises repairs to walls, cladding and equipment.

Shock-absorbing performance

ImpactSAFE buffers reduce force transfer and improve durability.

Space-efficient design

Low-profile construction maintains usable floor space.

Flexible configuration

Adaptable to different impact risk levels.

Improves safety in high-traffic areas

Enhances protection where vehicles operate close to structures.

Compatible with wider safety systems

Integrates with Armco accessories and pedestrian solutions.

Technical Overview

• Product: Armco Wall Mounted Safety Barrier
• Material: Steel and rubber
• Height: 420 mm
• Barrier profile: 310 mm x 85 mm Armco rail
• Projection: Approx. 165 mm from wall
• Fixings: M12 x 160 mm coach screws with nylon rawl plugs
• Drill specification: 14 mm diameter, 100 mm depth
• Fixing centres: 1.6 m (high impact), 3.2 m (low impact)
• Colour options: Galvanised steel with black rubber buffers
• Installation surface: Brick, block and pre-cast concrete

Summary

The Armco Wall Mounted Safety Barrier is a compact and cost-effective solution for protecting walls, equipment and infrastructure from vehicle impact. With its low-profile design, integrated ImpactSAFE shock absorption and durable steel construction, it provides reliable protection without compromising space or operational efficiency. Suitable for a wide range of industrial environments, it is an essential addition to any safety-conscious facility looking to reduce damage, improve safety and maintain long-term performance.
