Verified by manufacturer 3 days ago
Araipur100LED
Certificate of Conformity
Certificate type
Certificate of Conformity
Certificate type
Quiet aerator for odour and humidity extraction from WC pan and bathroom air. Optional LED and humidity sensor. Compatible with Valsir Tropea S and Winner S cisterns.
Ariapur is a bathroom aerator that eliminates odours and improves air quality by extracting directly from the WC pan and the surrounding environment. Designed to fit compactly within bathroom spaces—particularly windowless or poorly ventilated rooms—it connects to the wastewater ventilation stack to remove smells before they spread.
Ariapur also removes steam from showers and baths via the suction plate and can operate automatically with a humidity sensor.
Features and benefits:
Color | White |
Finish | Matt |
Material | Polypropylene |
Shape | Square |
Length | 250 mm |
Width | 130 mm |
Height | 250 mm |
Warranty description | Ten year |
Uniclass | |
CAWS | U9/306 Wall-mounted extract fans U9/302 Ceiling-mounted extract fans U90/413 Ventilation fan units |
SKU Code | VS085xxxx |
Classification data | |
Performance characteristics | |
Duty | 85 m³/h with up to 30 minute overrun. 100 m³/h with up to 30 minute overrun. Manufacturer guidanceThe Araipur100LED version is equipped with a timer that can be set from 2 to 30 minutes for timed shutdown. |
Mounting | Wall. Ceiling. |
Controls | Switch. Linked to light switch. Motion sensor. |
Accessories | Integrated 12 W neutral white LED light and filter. Guidance for specification option: The fans and LED light can be activated seperately. |
Dimensions | 250 x 130 x 250 mm. |
SoundPressure | Up to 35 dB(A). Guidance for specification option: Noise level at 3 m distance, maximum speed. |
Ingress protection (IP) rating | IPx5. |
Contains Red List materials | No |
Country of product manufacture | Italy |
Manufacturing plant location | |
Material | Polypropylene |
| Carbon dioxide equivalent | |
Carbon dioxide equivalent, as defined in BS EN 15804 Self-declared | |
Stage Normalised unit (kg CO₂ eq/kg) Declared unit (kg CO₂ eq/unit) Stage:A1–A3 ('Production stage') Normalised unit : 2.621 (kg CO₂ eq/kg) Declared unit : 31.448 | |
Recyclability | After the demolition and deconstruction phase, can be incinerated, sent to landfill or recycled |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 57 % |
Expected Life | 50 year |
