Aqua illi - Boiling, Chilled & Sparkling (BCS) Water Tap - Fully Integrated Water Tap System
Verified by manufacturer 1 day ago
Aqua Libra Studio
Aqua Libra Studio
KIWA BDA
Certificate type
KIWA BDA
Certificate type
Fully integrated water tap system delivering purified hot, chilled still, and sparkling water; available in polished and matte black as standard.
Application
Suitable for a variety of environments including workplace & offices, education, healthcare and hospitality.
Particularly suitable for glasses, cups and short bottles in the following applications:
- Office/workplace breakout rooms.
- Executive lounges.
- Staff rooms.
- Wellness and spa areas.
Description
The Aqua illi is a fully integrated tap system for modern workplaces, delivering purified hot, chilled, sparkling, and ambient water in a sleek design that seamlessly complements any interior for effortless, dependable hydration.
Features and benefits:
- Robust; intuitive; beautifully minimal.
- Designed to withstand high daily use.
- Engineered for teams who value form and function.
- Less visual clutter - more clarity.
- Patented boiler design gives high volumes of boiling water
- Featuring Aqua Purifier four-stage + PFAS/microplastic filtration
- Installed in modular form
- Perfect water flow
- Continuous and timed dispensing modes to accommodate precise fill volumes
- Tap height extensions are available for dispensing into a variety of vessel sizes
- Plumbed-to-waste
- Flush-fitting drip tray
- Safe hot dispense with a touch padlock feature
- Removable dispense nozzle for improved hygiene
- Equality Act - Compliant options available
- Regulation 4 Certified
General information
Color | Black Silver Other Beige Blue |
Finish | Matt Polished Coated Chrome Electro polished |
Material | Steel |
Shape | Other |
Length | 155 mm Manufacturer guidanceSpout depth (overall). |
Width | 45 mm Manufacturer guidanceSpout diameter. |
Height | 298 mm 358 mm 408 mm Manufacturer guidanceSpout height (overall). |
Warranty description | One year |
Uniclass | |
CAWS | N12/380 Sinks, taps, traps and wastes N12/380 Sinks, taps, traps and wastes N11/350 Sinks, taps, traps and wastes N11/30 Sinks, taps, traps and wastes |
Specification data - Instant boiling and cold water taps
Classification data | |
Water | Boiling, chilled, sparkling. |
Duty | |
Tank capacity | Up to 45 litres. |
Hot cups | 180 per hour at 250 mL. Guidance for specification option: Glasses for chilled or sparkling water. |
Cold cups | 180 per hour at 250 mL. Guidance for specification option: Glasses for chilled or sparkling water. |
Dimensions | Tap: 298 mm high; 155 mm deep; 45 mm diameter column. Cabinet: 900 x 600 x 600 mm. Guidance for specification option:
|
Electrical connection | |
Power | 3 No. 50 Hz single switched 13 A power sockets. |
Voltage | 220–240 V. |
Water inlet | 1 No. potable cold mains water supply terminating in a 15 mm Ballofix isolation valve - compression connection. |
Safety features | Touch operated. |
Components | Touch tap; flush-fitting round drip tray; CTO filter; purifier storage tank; purifier; dry sparkling cooler; standard boiler. · CO₂ bottle to be supplied by others. Guidance for specification option: The manufacturer asks that customers order gas cylinders in advance.
Consult manufacturer for recommendations and related technical requirements. |
Colour/ Finish | Guidance for specification option: Bespoke colour matching - consult manufacturer for details of colour, material and finish options, and insert requirements. |
Extension | Not required. Guidance for specification option: 234 mm dispense height; 298 overall visible height. Additional 60 mm height. Guidance for specification option: 294 mm dispense height; 358 overall visible height. Additional 110 mm height. Guidance for specification option: 344 mm dispense height; 408 overall visible height. |
Accessories | Cover plate. Guidance for specification option: Cover plate options available for replacing existing fixtures. Colour/ finish to match tap unless specified otherwise. Not required. |
Water pressure | 2.5 bar (minimum). |
Flowrate | 300 L/h (minimum). |
Ventilation | Required. Guidance for specification option:
|
Power consumption | Peak: 1750 W. |
Current | Peak: 8 A. |
Waste | Requires 40 mm upstand trapped waste pipe, 500 mm high. |
Sustainability data
Contains Red List materials | No |
Country of product manufacture | United Kingdom |
Material | Steel |
Expected Life | Five year |
