Aqua Flavour Tap Nano - Boiling, Chilled, Sparkling & Flavoured Water Tap - Fully Integrated Water Tap System
Verified by manufacturer 2 days ago
NANO LHS installation (inc. boiling water)
NANO LHS installation (inc. boiling water)
Fully integrated water tap system delivering purified boiling, chilled, sparkling and flavoured water.
Application
Suitable for a variety of environments including workplace and offices, education, healthcare and hospitality.
Particularly suitable for glasses, cups and short bottles in the following applications:
- Office/workplace breakout rooms.
- Micro kitchens
- Executive lounges.
- Staff rooms.
- Wellness and spa areas.
Description
Flavour Tap Nano brings still, sparkling, flavoured, electrolyte and hot water together in one integrated tap.
Every tea point and pantry can also become a fully fledged hydration station, keeping workplaces hydrated smoothly with built-in smart monitoring and intuitive controls.
Features and benefits:
- All-in-one: still, sparkling, flavoured and functional water from a single tap.
- Connected technology: IoT enabled reporting, predictive servicing and simple monitoring.
- Intuitive by design: touch controls, quick flavour swaps, effortless for everyone to use.
- Space efficient: countertop and standalone options to suit your space.
- Functional choices: options with electrolytes, including zinc to support immunity.
- Sustainable by design: helps cut single use packaging with every refill.
General information
Color | Black Silver Other Beige Blue |
Finish | Matt Polished Coated Chrome Electro polished |
Material | Steel |
Shape | Other |
Length | 169 mm Guidance for specification option: Spout depth (overall). 600 mm Guidance for specification option: Cabinet (external). |
Width | 40 mm Guidance for specification option: Spout diameter. 1200 mm Guidance for specification option: Cabinet (external; boiling water variants). 600 mm Guidance for specification option: Cabinet (external; non-boiling water variant). |
Height | 336 mm Guidance for specification option: Spout height (overall; no extension). 1236 mm Guidance for specification option: Spout and cabinet height (overall; no spout extension). Manufacturer guidanceSpout height (overall). |
Warranty description | One year |
Uniclass | |
CAWS | N12/380 Sinks, taps, traps and wastes N11/30 Sinks, taps, traps and wastes N11/350 Sinks, taps, traps and wastes N12/380 Sinks, taps, traps and wastes |
Specification data - Instant boiling and cold water taps
Classification data | |
Water | Boiling, chilled still, flavoured still, sparkling. |
Duty | |
Tank capacity | Manufacturer's standard. Guidance for specification option: Consult manufacturer for details. |
Hot cups | Manufacturer's standard. Guidance for specification option: Consult manufacturer for details. |
Cold cups | Manufacturer's standard. Guidance for specification option: Consult manufacturer for details. |
Dimensions | Tap: 336 mm high; 169 mm deep; 40 mm diameter column; dispenser height: 269 mm. Cabinets: two, 900 x 600 x 600 mm. Guidance for specification option: Cabinet dimensions are external only; consult installation guidance for further details. |
Electrical connection | |
Power | 3 No. 50 Hz single switched 13 A power sockets. |
Voltage | 220–240 V. |
Water inlet | 1 No. potable cold mains water supply terminating in a 15 mm Ballofix isolation valve - compression connection. |
Safety features | Touch operated. |
Components | Nano touch tap; PSU; purifier storage tank; CTO filter; flavour rack; purifier; standard boiler; BSP sparkling cooler. · CO₂ bottle to be supplied by others. Guidance for specification option: The manufacturer asks that customers order gas cylinders in advance.
Consult manufacturer for recommendations and related technical requirements. |
Colour/ Finish | Aqua Libra Studio. Guidance for specification option: Bespoke colour matching - consult manufacturer for details of colour, material and finish options, and insert requirements. |
Water pressure | 2.5 bar (minimum). |
Flowrate | 300 L/h (minimum). |
Ventilation | Required. Guidance for specification option:
|
Power consumption | Peak: 1750 W. |
Current | Peak: 8 A. |
Waste | Requires 40 mm upstand trapped waste pipe, 400 mm high. |
Sustainability data
Contains Red List materials | No |
Country of product manufacture | United Kingdom |
Material | Steel |
