Name: Ancon Expansion Bolts
Brand: Leviat
SKU: mockKb99dqH2m7xtygBRnq

Color

Silver

Material

Stainless steel

Uniclass

Pr_20_29_03_28 Expansion anchorsPrimary

CAWS

F30/290 Proprietary special fixings

Classification data

Product Reference

FBNII 6/10 Single Expansion Bolt

Guidance for specification option:

M6 x 55 mm long overall.

FBNII 8/10 Single Expansion Bolt

Guidance for specification option:

M8 x 71 mm long overall.

FBNII 10/20 Single Expansion Bolt

Guidance for specification option:

M10 x 96 mm long overall.

FBNII 10/50 Single Expansion Bolt

Guidance for specification option:

M10 x 126 mm long overall.

FBNII 12/20 Single Expansion Bolt

Guidance for specification option:

M12 x 116 mm long overall.

FBNII 12/50 Single Expansion Bolt

Guidance for specification option:

M12 x 146 mm long overall.

FBNII 16/25 Single Expansion Bolt

Guidance for specification option:

M16 x 145 mm long overall.

FBNII 16/50 Single Expansion Bolt

Guidance for specification option:

M16 x 170 mm long overall.

FAZII 8/10 High Performance Bolt

Guidance for specification option:

M8 x 75 mm long overall.

FAZII 10/10 High Performance Bolt

Guidance for specification option:

M10 x 95 mm long overall.

FAZII 10/30 High Performance Bolt

Guidance for specification option:

M10 x 115 mm long overall.

FAZII 12/30 High Performance Bolt

Guidance for specification option:

M12 x 130 mm long overall.

FAZII 12/50 High Performance Bolt

Guidance for specification option:

M12 x 150 mm long overall.

FAZII 16/25 High Performance Bolt

Guidance for specification option:

M16 x 148 mm long overall.

FAZII 16/50 High Performance Bolt

Guidance for specification option:

M16 x 173 mm long overall.
