Amtico Signature LVT Tile 36+ Acoustic – Stone

Verified by manufacturer 5 months ago

Amtico International

Amtico Acoustic introduces a high performance sound reduction backing that works across standard tiles and planks in our Signature collection.

Jump to:
BIM object icon
+44 (0)121 745 0800 Website

Application

Tiling applications.

Description

Amtico Signature is a premium product that can be cut and combined in an infinite number of ways to help deliver individual creative vision for a variety of commercial sectors. Amtico's flagship product collection, containing 217 products that push the boundaries of what can be achieved through cutting edge design.


This collection has a thicker 1.0 mm wear layer offering longevity and is suitable for high traffic areas in healthcare, retail, office, education, hospitality and leisure commercial housing, government buildings and commercial spaces.


Performance:

  • Light stability (ISO 105-B02): ≥6.
  • Curl (EN 434): ≤2 mm.
  • Electrostatic performance (ISO 6356): <2kV.


Laying patterns:

Amtico products can be laid in a range of design patterns. Consult Amtico for further information.


Custom Design:

Create your own floor, combine products and create any design of your invention. From company names and logos to large scale bespoke plans. Consult Amtico to for further information.


Amtico Acoustic:

Amtico Acoustic can be specified as a backing option with the Signature Collection. The specially developed closed-cell foam structure dampens noise by up to 18 dB, whilst also helping to reduce fatigue in high traffic areas.

General information

Color

Beige

Grey

Other

Finish

Anti-slip

Material

PVC

Shape

Square

Rectangle

Length

304.8 mm

457.2 mm

609.6 mm

914.4 mm

1219.2 mm

Width

76.2 mm

114.3 mm

152.4 mm

184.2 mm

228.6 mm

Show more

Height

2.5 mm

WarrantyDescription

20 year

Uniclass

Pr_35_57_71_62 Particle-based enhanced slip-resistant polyvinyl chloride (PVC) tilesPrimary

CAWS

M50/10 Resilient floor tiling

M50/110 Resilient floor tiling

Specification data - Particle-based enhanced slip-resistant polyvinyl chloride (PVC) tiles

Use class

To EN 685, class 23, 34, 43.

Slip potential

-

Slip resistance value (SRV) (minimum)/ Pendulum test value (PTV) (minimum)

To DIN 51130, R10.

Recycled content

Amtico Signature is recyclable and has been assessed and certified as A+/A by the Building Research Establishment Environmental Assessment Method (BREEAM).

-

Size

152.4 x 457.2 mm.

304.8 x 304.8 mm.

304.8 x 457.2 mm.

457.2 x 457.2 mm.

304.8 x 609.6 mm.

457.2 x 914.4 mm.

184.2 x 1219.2 mm.

228.6 x 1219.2 mm.

76.2 x 914.4 mm.

114.3 x 914.4 mm.

152.4 x 914.4 mm.

609.6 x 1219.2 mm.

Thickness

2.5 mm.

Colour and pattern

Consult Amtico for details of colours and finishes.

-

Wear layer thickness

1 mm.

Weight

3350 g/m².

Abrasion resistance

To EN 651, Group T.

Slip resistance class

To DIN 51130 and EN 13893, DS.

Residual indentation

To EN ISO 24343-1, ≤0.20 mm.

Dimensional stability

To EN ISO 23999, Pass.

Flammability

To EN 13501-1, Bfl-s1.

Thermal resistance

To EN ISO 12664, 0.040 m²K/W (suitable for underfloor heating).

Sound reduction

To ISO 717-2, 18 dB.

Environmental information

Contains Red List materials

Yes

Country of material origin

UK, EU, USA, Japan, Taiwan.

-

Country of product manufacture

United Kingdom

Recyclability

Recyclable

Recycled content

13 %

BIM objects

BIM object icon

NBS BIM object standard

This BIM object has been authored to meet the requirements of the NBS BIM object standard.

Find out more about the NBS BIM object standard.

Platform Compatible Version
Revit
-

1

IFC
-

1
