Aluminium Standing Seam
Verified by manufacturer 6 months ago
Aluminium standing seams suited for residential and commercial applications and can be mounted vertically or horizontally.
Application
Suitable for residential and commercial applications.
Description
Seamless Aluminum Groups standing seam systems are designed and manufactured to provide the essential architectural features appropriate to any building design. A sustainable pre-painted aluminium roofing and cladding system designed for the residential and commercial market. Standing seam can be mounted vertically or horizontally.
Manufactured on site in Ballyshannon, Co Donegal in marine grade Aluminium to ensure its high quality and so they can accommodate any special requirements in relation to length, colour, special angles or brackets etc.
Features and benefits:
- Quick fit system reduces installation time on site.
- Can be installed on a roof with a pitch as low as 3°.
- Several times lighter than traditional roof tiles.
- Extremely flexible and easy to work with.
- Can tolerate high pressure.
- Available in various lengths and widths.
- Bespoke trims available to order.
- Dedicated technical team available for design support.
- Low maintenance life in excess of 40 years in rural and suburban conditions and in excess of 25 years in industrial and marine conditions.
- Manufactured under the ISO 9001 - 2015 quality management standards.
General information
Color | White Black Grey Brown Other Guidance for specification option: Available in any RAL or classic BS colours. |
Finish | Powder-coated |
Material | Aluminium |
Shape | Other |
Length | 4000 mm Bespoke Guidance for specification option: Maximum. Manufacturer guidanceUp to 4,000 mm. |
Width | 306 mm Bespoke Guidance for specification option: Consult manufacturer and insert requirements; available in widths 70–450 mm upon request. |
Height | 25 mm |
Warranty description | 20 year |
Uniclass | |
CAWS | H31/110 Metal H31/120 Metal H72/370 Standing seam verge H72/340 Standing seam eaves H72/725 Standing seam sliding clips H72/720 Standing seam fixed clips H72/20 Standing seam eaves H72/67 Standing seam joints |
Specification data - Aluminium profiled sheets
Standard | |
Sheet roofing and cladding products | To BS EN 485, EN 15088 and EN 1396. |
Sheet, strip and plate | To BS EN 485, EN 15088 and EN 1396. |
Grade | EN-AW-1050A. |
Temper | H14. |
Thickness (nominal) | 0.7 mm. |
Profile | |
Form | Standing seam. |
Height | 25 mm. |
Side 1 (outer) | |
Factory finishes | Powder-coated. |
Colour | Traffic white (RAL 9016).Guidance for specification option: Standard RAL colour. Jet black (RAL 9005).Guidance for specification option: Standard RAL colour. Slate grey (RAL 7015).Guidance for specification option: Standard RAL colour. Anthracite grey (RAL 7016).Guidance for specification option: Standard RAL colour. Zink grey (RAL 7030).Guidance for specification option: SaluZinc™ colour. Blue grey (RAL 7031).Guidance for specification option: SaluZinc™ colour. Light grey (RAL 7005).Guidance for specification option: SaluZinc™ colour. Grey (7016).Guidance for specification option: SaluZinc™ colour. Brown.Other.Guidance for specification option: All powder-coated products available in any standard RAL colour. Consult manufacturer and insert requirements. |
Reaction to fire | |
External face | Non-combustible to EN 13501-1.Guidance for specification option:
|
Internal face | Non-combustible to EN 13501-1.Guidance for specification option:
|
Length | Guidance for specification option: Consult manufacturer and insert requirements; available in lengths up to 4 meters. |
Width | 306 mm. Guidance for specification option: Standard. Bespoke. Guidance for specification option: Consult manufacturer and insert requirements; available in widths 70–450 mm upon request. |
Gauge | 0.7 mm. |
Panel Type | Standing seam panel type A. Standing seam panel type B. Standing seam panel type C. Standing seam panel type D. Standing seam panel type E. Manufacturer guidanceConsult manufacturers literature for further information on panel types. |
Accessories | Not required. Z channel. Fixing bracket. Ridge cap T10. Gable end trim T9. Guidance for specification option: See tech drawings for trims. |
Sustainability data
Contains Red List materials | No |
Country of material origin | Norway |
Country of product manufacture | Ireland |
Recyclability | 100% |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 100 % |
