Aluminium Roller Shutter - CD60 Built on Seceuro

Verified by manufacturer 15 days ago

HAG Ltd. - The Door Specialists Third party certifications:
  • ADSA

    ADSA

    Certificate type

  • Alcumus SafeContractor

    Alcumus SafeContractor

    Certificate type

  • CHAS

    CHAS

    Certificate type

  • Constructionline

    Constructionline

    Certificate type

  • dhf certificate

    dhf certificate

    Certificate type

  • ISO 9001 Quality Management

    Certificate type

60 mm heavy-duty double-skin aluminum roller shutter, offering enhanced security and the ability to span larger openings.

Jump to:
0800 072 3444 Website

Application

Fire shutter suitable for industrial, commercial, residential, public buildings, hospitality and cultural or historical settings

  • Airports
  • Train stations
  • Kitchen servery hatches
  • Retail units
  • Shopping malls
  • Offices
  • Leisure complex
  • Warehouse
  • Factories
  • Chemical plant
  • Hospitals
  • Care homes
  • Receptions areas
  • Schools
  • Colleges
  • Academies
  • Universities
  • Nurseries
  • Residential - high rise or large houses
  • Hotels
  • Restaurants
  • Museums
  • Libraries
  • Historical sites


Description

Roller shutter constructed with 60mm thick double-walled aluminum for enhanced security.

Features and benefits:

  • Spring loaded or electric operation available depending on requirements.
  • Available in stock colours (brown, white, black or cream) with alternative powder coating at additional cost.
  • Recommended maximum width up to 6000 mm.

Shutter box:

  • Manufactured from roll formed aluminium.
  • The bottom box is removable for installation and maintenance and chamfered at 45°.
  • The shutter box is assembled on die cast aluminium end plates.

Shutter curtain:

  • 55 x 14 mm double skinned extruded aluminium non vented slat.

General information

Color

Black

White

Brown

Other

Finish

Powder-coated

Guidance for specification option:

Polyester powder-coated (PPC).

Material

Aluminium

Guidance for specification option:

60 x 14 mm, double walled.

Shape

Rectangle

Length

Bespoke

Width

Bespoke

Manufacturer guidance

Maximum width.

Height

Bespoke

Warranty description

One year

Uniclass

Pr_30_59_84_73 Roller shuttersPrimary

CAWS

L20/60 Doors

L20/610 Roller shutters/ curtains

Product range

Seceuro Roller Shutters

Specification data - Roller shutters

Opening sizes

-

Manufacturer guidance

Insert requirements, maximum width: 6000 mm.

Format

Internal.

External.

Arrangement

Vertical operation.

Shutter curtain.

-

Lath material

Aluminium.

Guidance for specification option:

Double walled.

Profile

Curved.

Guidance for specification option:

60 x 14 mm.

Finish and colour

Black.

White.

Cream.

Dark Brown.

Manufacturer guidance

Polyester powder-coated, stock colour. For special order, RAL/ BS colours; consult manufacturer for details and insert requirements.

Frame and guides

-

Material

Aluminium.

Finish

Polyester powder-coated.

Colour

Black.

White.

Cream.

Dark Brown.

As shutter curtain.

Manufacturer guidance

Stock colour. For special order, RAL/ BS colours; consult manufacturer for details and insert requirements.

Operation

-

Mode

Manual, spring loaded.

Guidance for specification option:

A counter balanced spring ensures controlled raising and lowering with a key lock in-built at the bottom of the shutter for security.

Electrical, single phase.

Guidance for specification option:

  • Provision of a 13 A fused spur is required for installation.
  • A tubular motor within the barrel assembly with limit switches and the thermal cut out to prevent overheating.
  • Draw 240 V and 0.5–2.5 A dependent upon the shutter size.

Control

Rocker switch.

Security key switch.

Accessories

None.

Manual override.

Guidance for specification option:

A manual override should be priced and ordered separately for shutters which are to be installed on exit doorways to permit operation in the event of a power failure. This is usually only operable from only one side.

Sustainability data

Contains Red List materials

No

Country of material origin

United Kingdom

Country of product manufacture

United Kingdom

Material

Aluminium

Guidance for specification option:

60 x 14 mm, double walled.

Recyclability

95

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

75 %

Third party certifications

ADSA

ADSA Membership

Alcumus SafeContractor

Alcumus Safe Contractor Certificate of Accreditation

CHAS

CHAS Certificate of Accreditation

Constructionline

Construction Line Gold Membership

dhf certificate

DHF Full Member

ISO 9001 Quality Management

ISO 9001

Alcumus SafeContractor

SAFE PQQ Alcumus Safe Contractor
