Alumasc Rainwater Infinity Steel Half Round Gutters
Verified by manufacturer 4 months ago
HRS40
HRS40
UKAS
Certificate type
Galvanized steel half round gutter profile.
Application
- For use in commercial, healthcare, public sector and residential settings.
- Suitable for traditional and modern buildings in both new build and refurbishment applications.
Description
Steel half round gutter are available in four sizes and one length, together with a complete range of fittings. Lightweight range of contemporary, eco friendly and cost effective alternative to plastic gutters, without the risk of shrinking, leaking or colour fading.
Features and performance:
- Available in four sizes.
- Complete with range of fittings.
- Lightweight, durable and non-corrodible.
- Plain end with external union.
- Quick and easy installation.
- Life expectancy in excess of 25 years.
- Low maintenance.
- Manufactured to ISO 9001: 2008.
- All gutter widths are deep half round providing maximum flow rates.
- Higher flow capacity on outlets due to larger inlet funnels.
- Gutter angle is 'deep drawn' and one piece giving greater flow capacity.
- Quick and easy installation.
- Fascia bracket has a larger back plate for installation ease and six fixing points compared to two on other systems.
General information
Color | Black Grey Brown Silver Other |
Finish | Galvanized Coated |
Material | Steel |
Shape | Other Guidance for specification option: Half round. |
Length | 3000 mm |
Width | 115 mm 125 mm 150 mm 190 mm |
Height | 70 mm 80 mm 90 mm 100 mm |
Warranty description | 15 year |
Uniclass | |
CAWS | R10/14 Continuously hot dip coated steel gutters R10/332 Continuously hot dip coated steel gutters R10/335 Galvanized steel gutters |
SKU Code | HRS40, HRS50, HRS60, HRS75 |
Product range |
Specification data - Galvanized steel combined fascias, soffits and gutters
Form | Rolled. |
Third-party product certification | ISO 9001, ISO 14001; EN10169-2. |
Gutters | |
Profile | Half round. |
Size | 115 x 70 mm. |
Finish | Galvanized. Pre-coated. |
Colour | Galvanized Steel. RAL 7016m Anthracite Grey. RAL 9005m Black. RAL 9007MET Aluminium Grey. RAL 6005 Moss Green. RAL 7037m Dusty Grey. RAL 8004m Copper Brown. RAL8014m Sephia Brown. RAL9002 Grey White. |
Integral accessories | Angles. Brackets. Outlets. Stop Ends. Unions. |
Fire rating (to BS EN 13501) | A2. |
Type | Plain end with external union. |
Standard | To BS9101: 2017. |
Protection | Corrosion protection. |
Bonding primer | Primer bonding coat. |
Top coat | Polyester top coat. |
Sustainability data
Contains Red List materials | No |
Country of product manufacture | Germany |
Material | Steel |
Recyclability | 100% |
BIM objects
| Platform | Compatible | Version |
|---|---|---|
 Revit | - | 1 |
Third party certifications
UKAS
ISO 14001 - Burton Latimer site
UKAS
ISO 9001 - Burton Latimer site
