AluK F82 Plus Thermally Broken Residential Door System
Verified by manufacturer 4 months ago
Single Leaf: Anodized.
Single Leaf: Anodized.
Secured By Design
Certificate type
QA Certificate
Certificate type
Thermally broken aluminium residential door.
Application
Suitable for use with residential new build and refurbishment projects, ideal for light and medium traffic environments.
Description
Thermally broken aluminium residential door.
Features and benefits:
- Fully symmetrical frame sightline.
- Low threshold option.
- Doors are Secured by Design accredited and are Q-Marked in accordance with PAS 24.
- Aluminium profiles are extruded in accordance with BS EN 12020, and are manufactured from grade 6060/6063 T6 aluminium.
- Compliant with ADL1/ ADL2 capable of achieving U-values of 0.9 W/m²K.
- A variety of powder coated colours are available in accordance with BS 6496 and BS EN 12206-1:2004.
- Powder coating is applied to a Qualicoat standard, utilizing an inline flash anodizing pre-treatment process, with the polyester powder coating applied within 30 minutes of the flash anodizing process to ensure suitable adhesion.
- Doors can be dual coloured, textured or have an anodized finish.
General information
Color | Other Insert RAL colour requirement or type 'Not applicable' for anodized. |
Finish | Anodized To a minimum 15 micrometres thickness. Powder-coated |
Material | Aluminium Glass |
Shape | Rectangle |
WidthRecommended maximum size limits (maximum). | 1200 mm Single door - Hardware limits. Single door - Tested limits. 2495 mm Double door - Hardware limits. Double door - Tested limits. |
HeightRecommended maximum size limits (maximum). | 2500 mm Single door - Tested limits. Double door - Tested limits. 2600 mm Single door - Hardware limits. Double door - Hardware limits. |
Uniclass | |
CAWS | L20/480 Doorsets L20/55 Doorsets |
Product range |
Specification data - Aluminium doorsets
Configuration | Single leaf, open in.Single leaf, open out. |
Doorset size | 1200 x 2600 mm.Maximum size: Hardware limits. 1200 x 2500 mm.Maximum size: Tested limits. As drawing.Insert requirement. As schedule.Insert requirement. |
Performance | - |
Thermal | 1.3 W/m²K. |
Intruder resistance | - |
Minimum requirement | Secured by Design certification and PAS 24. |
Frame | - |
Material | Aluminium. |
Threshold | As drawing.Low threshold.As option. |
Finish | - |
Coating | Anodized.To a minimum 15 micrometres thickness. |
Texture | Not applicable. |
Colour | Anodized. |
Door leaf | - |
Core | Manufacturer's standard. |
Material | Aluminium. |
Glazing | - |
Type | Glass panels.28–44 mm glass look-a-like panels, insert requirements. Glass look-a-like panels incorporating two panes of minimum 6 mm thick glass, with a 16 mm argon gas filled cavity and ceramic painted internal face with foil backed insulation to achieve a maximum 0.35 W/m²K centre pane. Exposed internal faces of insulation incorporate an internal polyester powder coated aluminium tray backing. Glazing.28–44 mm insulating glass units, insert requirements. Insulating glass units incorporating a clear low emissivity inner pane and a clear outer pane with an argon gas filled cavity and 'warm edge' spacer bar to achieve a maximum centre pane U-value of 1.0 W/m²K. All glass within 800 mm from FFL should be toughened or laminated (within 1500 mm from FFL if within 300 mm of a door). Infill panels.28–44 mm insulated sandwich panels, insert requirements. Insulated sandwich panels incorporating two sheets of a minimum 2 mm thick polyester powder coated aluminium sheet to match framing and minimum 24 mm non-combustible foam insulation core. |
Beading | - |
Type | Square. |
Material | Aluminium. |
Finish | - |
Coating | Anodized.To a minimum 15 micrometres thickness. |
Texture | Not applicable. |
External colour | Anodized. |
Internal colour | As External. |
Film thickness (minimum) | 15 micrometers. |
Accessories | Not required.U61631.20 mm add on. U61632.40 mm add on. Fanlight.Insert requirements. Laybar.Insert requirements. Letterplate.Insert requirements. Midrail.Insert requirements. Sidelight.Insert requirements. |
Outer frame | U61060. Flush frame. U61200. Rebated frame. |
Sub sill | Not required. U61630. 190 mm sill. |
Ironmongery | Insert requirements. Full range of suited hardware available consult manufacturer. |
Vent | U61300 - Sash. |
Panel weightMaximum panel weight. | 150 kg. |
Air permeability | Class 4 (600 Pa). |
Watertightness | Class 5A (200 Pa); E900 (900 Pa). Open in: Class 5A (200 Pa); open out: E900 (900 Pa). |
Wind resistance | 1200 Pa. |
Environmental information
Country of product manufacture | United Kingdom |
