Alloy Bathroom Wall Panels - Water Resistant Wall Panels

Verified by manufacturer 2 days ago

Solid Colour Range

Wilsonart Variant:

Water-resistant shower panel with composite mineral core and decorative coated aluminium face.

Jump to:
+44 (0)1388 770 138 Website

Application

Suitable for use internally in bathroom, shower areas.

Description

Wetwall™ Alloy - Aluminium Composite shower panels are available in different variations and sizes with aluminium trims, that can be used in combination for wall lining a wide variety of bathroom layouts

The 4 mm thick panel system is manufactured using a composite substrate and aluminium facing.

The panels are characterised by excellent rigidity and toughness but are lightweight. This product has good dimensional stability and is not susceptible to decay, rotting and other degeneration processes.

Features and benefits:

  • Various decor and solid colour options.
  • Water resistant.
  • Fire classification to EN 13501-1, Class B-s1, d0.
  • Salt spray resistant.
  • Solvent and chemical resistance.
  • Range of sizes.
  • Square edge.
  • Multiple trims and endcaps available.
  • Suitable layouts include: Two-sided, three-sided, two-sided wide, and shower/ bath combination.
  • Can be cut to size
  • Lifetime Warranty*

*Warranty is validated provided that the installation of the product follows our installation guidance and uses our accompanying trims, sealants and adhesives.

General information

Color

Beige

Black

Blue

Cream

Brown

Show more

Finish

Gloss

Matt

Material

Mineral board

Aluminium

Shape

Rectangle

Length

2440 mm

Width

600 mm

900 mm

1200 mm

Height

4 mm

Uniclass

Pr_25_71_43_52 Metal faced mineral-based lining boardsPrimary

CAWS

K13/160 Proprietary

N10/10 Purpose-made

N10/110 Purpose-made

N13/375 Shower units

K13/160 Proprietary

N13/355 Baths

Specification data - Metal faced mineral-based lining boards

Classification data

Product reference

Alloy Shower Panels.

Accessories

Not required.
End cap.
Internal corner.
External corner.
H-joint.
Shower niche.
Corner shelving.
Sealant.
Adhesive.

Reaction to fire

To EN 13501-1, B-s1, d0.

Thickness

4 mm.

Length

2440 mm.

Width

600 mm.
900 mm.
1200 mm.

Edges

Square.

Finish and colour

Gloss: Glacier white.

Guidance for specification option:

Solid colour range.

  • Neptune blue on reverse.

Gloss: Neptune blue.

Guidance for specification option:

Solid colour range.

  • Glacier white on reverse.

Gloss: Terra grey.

Guidance for specification option:

Solid colour range.

  • Seabreeze green on reverse.

Gloss: Seabreeze green.

Guidance for specification option:

Solid colour range.

  • Terra grey on reverse.

Matt: Midnight grey.

Guidance for specification option:

Solid colour range.

  • Hadrian green on reverse.

Matt: Hadrian green.

Guidance for specification option:

Solid colour range.

  • Midnight grey on reverse.

Gloss: Malibu grey.

Guidance for specification option:

Solid colour range.

  • Storm blue on reverse.

Gloss: Storm blue.

Guidance for specification option:

Solid colour range.

  • Malibu grey on reverse.

Matt: Deep sea blue.

Guidance for specification option:

Solid colour range.

  • Smoked rose on reverse.

Matt: Smoked rose.

Guidance for specification option:

Solid colour range.

  • Deep sea blue on reverse.

Matt: Seafoam green.

Guidance for specification option:

Solid colour range.

  • Battleship grey on reverse.

Matt: Battleship grey.

Guidance for specification option:

Solid colour range.

  • Seafoam green on reverse.

Core

Composite mineral core.

Facing

Aluminium sheet.

Colour

Aluminium, polished silver.
Aluminium, matt black.

Weight

6.48 kg/m².

Deflection

85°C.

Manufacturer guidance

Heat deflection temperature.

Peel strength

≥5 N/mm.

Temperature resistance

-50°C to +80°C.

Solvent resistance

100 MEK Double rubs, no change.

Chemical resistance

2% HCL or 2% NaOH for 24 hours, no change.

Gloss level

≥90 Gloss.
≥30/ 40 Matt.

Sustainability data

Material

Mineral board
Aluminium

Literature

Alloy Shower Panels - Technical Data Sheet

Alloy Shower Panels - Technical Data Sheet
