Verified by manufacturer 26 days ago
BBA Agrément Certificate
Certificate type
Direct fixed clay brick slip external wall insulation (EWI) system.
Mechanically and adhesively fixed to masonry, concrete, block or no-fines supporting walls.
The AlivaBrick E system consists of expanded polystyrene (EPS) insulation boards which are mechanically and adhesively fixed to masonry, concrete, block or no-fines supporting walls. A layer of basecoat with reinforcement mesh is applied to the mechanically fixed insulation boards and finishes applied. The system is then finished with a clay brick slip by embedding the slips into a cementitious bedding mortar and finished with a cement pointing grout.
Features and benefits:
Approved substrates:
Masonry, concrete, blockwork, aerated block and no-fines concrete.
Color | White Grey |
Finish | Brick |
Material | Clay Expanded polystyrene (EPS) |
Shape | Other |
Length | Bespoke |
Width | Bespoke |
Height | Bespoke |
Warranty description | Ten year |
Uniclass | |
CAWS | M21/210 Rendered external wall insulation systems M21/20 External wall insulation systems |
Classification data | |
Description | Direct fixed clay brick slip external wall insulation (EWI) system. |
Insulation | |
Material | Expanded polystyrene (EPS) boards, white. Expanded polystyrene (EPS) boards, grey. |
Adhesive | Adhesive layer to rear of board. |
Additional mechanical fixings | Mechanical fixing. Guidance for specification option: Consult manufacturer for details. |
Render carrier or reinforcement | |
Material | Reinforcing mesh. |
Mesh size | Manufacturer guidanceConsult manufacturer for details. |
Fixings | Mechanical fixing. Guidance for specification option: Consult manufacturer for details. |
Render | |
Application | Base coat. |
Material | Cementitious renders. |
Decorative finish | Clay brick slips, 9–25 mm thick, finished with a cement pointing grout. |
Colour | Manufacturer guidanceConsult manufacturer for details and insert requirements. |
Fire classification | Class B to BS EN 13501-1 (surface spread of flame). |
Material | Clay Expanded polystyrene (EPS) |
Expected Life | 30 year Guidance for specification option: The system when installed to specification will achieve a design life of in excess of 30 years. |
