NBS Source

Alitherm Plus Door

Verified by manufacturer 3 months ago

Smart Architectural Aluminium Third party certifications:
  • QA Certificate

    QA Certificate

    Certificate type

Thermally broken, aluminium, single or double doors.

Jump to:
+44 (0)1934 876100 Website

Application

All general light-use applications, including residential and light commercial.

Description

Thermally broken, aluminium, single or double doors incorporating innovative polyamide thermal break technology, which creates a barrier between the cold air outside and warm air inside. This technology significantly reduces thermal transmittance and enhances the overall U-value of the product.


The elegant, robust and high-performance entrance doors available in a range of formats and sizes. Designed for ease of fabrication and installation, Alitherm Plus doors feature adjustable hinges and lock keeps, with additional clearance for sash-passing to provide greater fitting tolerances.


Alitherm Plus can be fitted with the Smart Designer Door Panel range, which is carefully selected to suit a wide range of house and apartment styles. It is available in a choice of standard and non-standard colours, with single and dual colour options including Smart’s own Naturals, Sensations, Alchemy and Cotswold colour ranges.


Features and benefits:

  • An enhanced system designed to comply with the revisions to the Building Regulations (E&W), Document L compliant.
  • Marine grade 1.4401 (316) marine grade stainless steel hardware option.
  • Profiles feature an extended polyamide thermal break to enhance thermal performance.
  • Single and double door options.
  • Multi-point locking mechanisms.
  • Double doors feature dual lock mechanisms enabling handles on both sashes.
  • Adjustable hinges and lock keeps.
  • Door sections and hinges are designed with added strength to deliver robust performance.
  • Internally beaded for both open-in and open-out doors.
  • Low thresholds comply with Building Regulations (E&W) Document M.


General information

Color

Insert single or dual colour requirement from metallic, dual colour, Smart’s Sensations textured, and Alchemy anodized effect finishes.

-

Finish

Powder-coated

Material

Aluminium

Uniclass

Pr_30_59_24_02 Aluminium doorsetsPrimary

CAWS

L20/280 Doors

L20/45 Doors

Product range

Aluminium Doorsets

Specification data - Aluminium doorsets

Standard

Consult manufacturer and insert requirement.

-

Configuration

Double leaf, single action.

Features dual lock mechanisms enabling handles on both sashes.

Single leaf, single action.

Doorset size

Sash: 900 x 2100 mm (maximum).

W x H: Insert requirement.

Performance

-

Thermal

U-value: 1.8 W/m²K (maximum).

Intruder resistance

-

Minimum requirement

To PAS 24: 2012.

Conformity

Consult manufacturer and insert requirement.

-

Frame

-

Material

Aluminium.

Threshold

Low.

Compliant with Building Regulations (E&W) Document M.

Rebated.

Perimeter seals or inserts

Weatherseal.

Finish

-

Coating

Marine quality powder coat.

Texture

Manufacturer standard.

Colour

Insert single or dual colour requirement from Smart’s own Naturals, Sensations, Alchemy and Cotswold colour ranges.

-

Installation fasteners

Manufacturer standard.

Door leaf

-

Thickness

Dependent on glazing.

Core

Glazing.

Material

Aluminium.

Lippings

Manufacturer standard.

Perimeter seals

Weatherseal.

Beading

-

Type

Internal.

Material

Manufacturer standard.

Fixing

Manufacturer standard.

Finish

-

Coating

Marine quality powder coat.

Texture

Manufacturer standard.

External colour

Insert single or dual colour requirement from Smart’s own Naturals, Sensations, Alchemy and Cotswold colour ranges.

Insert single or dual colour requirement from Smart’s own Naturals, Sensations, Alchemy and Cotswold colour ranges.

Internal colour

Insert single or dual colour requirement from Smart’s own Naturals, Sensations, Alchemy and Cotswold colour ranges.

Insert single or dual colour requirement from Smart’s own Naturals, Sensations, Alchemy and Cotswold colour ranges.

Film thickness (minimum)

Manufacturer standard.

Hardware

Manufacturer standard.

Marine grade 1.4401 (316) stainless steel.

Art Deco.

Heritage.

Sightline

126.5 mm.

Perimeter edge/ thermal break

Extended polyamide thermal break.

Air permeability

To Class 4.

Watertightness

To Class 9A.

Resistance to wind load

To Class AE2400.

Locking

Multi-point locking mechanisms.

Sash

Sash: 100 kg (maximum).

Third party certifications

  • Kitemark: Certificate: KM 530838
