Application

Designed for use in domestic bathrooms, hotels and commercial applications.

Description

A back to wall horizontal outlet washdown WC suite with open flushing rim.


Features and benefits:

  • Valveless cistern siphon.
  • Flush volume: 4/ 2.6 L (dual flush).
  • Chrome plated lever handle.

General information

Color

White

Finish

Chrome plated

Material

Vitreous china

Length

355 mm

Width

520 mm

Height

390 mm

Uniclass

Pr_40_20_93_97 WC suitesPrimary

CAWS

N13/10 WC pans and flushing arrangements

N13/300 WCs and cisterns

Product range

WC suites

Specification data - WC suites

Approval

To EN 997, WC pans and WC suites with integral trap.

Standards

-

Cisterns

To EN 14055, WC flushing cisterns.

Pans

To BS EN 5627.

Form

A back to wall horizontal outlet washdown WC suite.

Materials

-

Body

Vitreous china.

Finish and colour

White, chrome plated.

Sizes

-

Cistern capacity

4/2.6 L dual flush.

Pan height

390 mm.

Cistern

CX9540XX, Concealed cistern, single flush, including lever, SSIO, with DAIV, 4 L.

CX9560XX, Concealed cistern, single flush, including lever, SSIO, 6 L.

CX9561XX, Concealed cistern, single flush, including lever, BSIO, 6 L.

CX9564XX, Concealed cistern, dual flush, including lever, SSIO, with DAIV, 6/ 4 L.

Chrome plated lever up to 114mm duct.

Flushing arrangement

Valveless cistern siphon.

Operation

Chrome plated lever handle as standard, for wall thicknesses up to 114 mm.

CF3017CP, Extended duct lever.

For wall thicknesses up to 340 mm.

CF3018CP, Extended duct lever.

For wall thicknesses up to 225 mm.

CF3109CP, Extended duct spatula lever.

For 114 mm wall depth.

CF9002CP, Air button, dual flush, small button.

For 3–40 mm panel depth.

CF9032CP, Air button, dual flush, mini plate 80 x 124 mm.

Minimum 65 mm panel depth.

Show more

Seat and cover

AR7851WH Alcona toilet seat and cover, wrapover, soft closing mechanism.

AR7915WH Alcona toilet seat and cover, wrapover, bottom fix hinge.

AR7857WH Alcona toilet seat and cover, wrapover, quick release hinge, soft closing mechanism.

AR7864WH Alcona toilet seat and cover, wrapover, top fix hinge.
