Advantage A or E

Application

Individually demountable for easy access to the soffit above.

Description

Ecophon Advantage sound absorbing panels which are individually demountable for easy access to the soffit above. Easy to install.

The system consists of Ecophon Advantage tiles and Ecophon Connect grid system with an approximate weight of 2.5 kg/m².

Features and benefits:

  • The tiles are manufactured from high density glass wool.
  • The visible surface is a high quality batch painted glass tissue in white colour and the back of the tile is covered with glass tissue.
  • Available with natural or primed edges (dependent on variant specified).
  • For best performance and system quality use Ecophon Connect grid and accessories.
  • The grid is manufactured from galvanized steel.


General information

Finish

Painted

Batch painted glass tissue - the surface allows the sound energy to penetrate into and be absorbed by the glass wool.

Color

White

Standard White 500 (nearest NCS colour sample S 0500-N, 83% light reflectance).

Features

Available with natural or primed edges (dependent on variant specified), individually demountable for easy access to the soffit above. Easy to install

Material

Tiles: High density glass wool

Grid: Galvanized steel

Shape

Square

Rectangular

Size

600 x 600 mm

1200 x 600 mm

WarrantyDescription

Full warranty available upon request

Uniclass 2015

Ss_30_25_22_90 Unit/ modular suspended ceiling systemsPrimary

CAWS

K40/10 Suspended ceilings

K45/13 Suspended ceiling system alterations

K45/160 Board-suspended ceiling system alterations

K45/130 Unit-suspended ceiling system alterations

K40/265 Infill units

K40/115 Unit/ modular suspended ceiling system

K45/120 Existing suspended ceiling system

K40/105 Suspended ceiling system

K45/12 Existing suspended ceiling system

Specification data - Unit/ modular suspended ceiling systems Enhanced data

Ceiling support

Interlocking Connect™ T15 grid

Interlocking Connect™ T24 grid

Support fasteners

Adjustable hangers/ wire

100 mm overall system depth.

Direct fixing brackets

50 mm overall system depth.

Ceiling units

High density glass wool tiles

System accessories

None

Connect™ Bridging Profile and Clip

For luminaire integration in panels.

Connect™ Edge Tool E

For cutting perimeter tiles.

Connect™ E-Plug

To cover gap profile and shadowline trim.

Connect™ Inspection Panel (C1) 0480

Connect™ Lighting Clip 0231 for T24

Connect™ Lighting Clip 0232 for T15

Connect™ Universal Clip

Connect™ Ventilation Grill

Edge Sealant

Insert colour requirement, consult manufacturer for information.

Product Reference

Advantage A

With exposed grid.

Advantage E

With recessed visible grid and tegular edge design.

Overall size

600 x 600 mm

1200 x 600 mm

Thickness:

15 mm

Edges

Natural

Not available for Advantage E.

Primed

Grid colour

Black 01 matt

Grey 01 metallic

For T4 only.

White 01

Weight

2.5 kg/m² (approximate including Connect grid system)

Demounting depth (minimum)

100 mm

Indoor climate

Recommended by the Swedish Asthma and Allergy Association. Certified as A+ by French VOC. Emission classification of building materials M1

Moisture resistance

The tiles withstand a permanent ambient RH up to 95% at 30°C without sagging, warping or delaminating (EN 13964)95% at 30°C without sagging, warping or delaminating

Fire safety

Complies with BS EN 13501-1, Class A2-s1, d0

Sound absorption

200 mm deep system: In accordance with EN ISO 11654, Class A

Cleaning

The ceiling system can withstand daily dusting and vacuum cleaning and weekly wet wiping

Environmental information

Contains Red List materials

No

Country of material origin

Sweden

Embodied carbon

2.53–2.73 kg CO₂ equiv/m² in conformity with ISO 14025/ EN 15804

Recycled content

50
