Active Floor - Sports Floor
Verified by manufacturer 2 months ago
Chain of Custody Certification
Certificate type
A low height, area elastic timber sports floor.
Application
Suitable for renovations and new build projects. This system provides high levels of shock absorption and uniform performance across the floor.
Active floor has a cross layered construction, making it very stable yet strong.
The finish is in European Oak and Ash timbers and is protected by the ultra sport lacquer. This is hard wearing and offers the correct levels of friction and slip resistance for all sporting activities.
The floor can be line marked with our specialist line marking paints and there is no requirement for additional on site applications of lacquer.
Reflex have numerous reference sites throughout the U.K. and mainland Europe.
Description
Reflex Active Floor is a sprung timber sports floor with the absorption material and reinforcements already fitted to the underside of the board to create an all-in-one solution.
The system features the smart-fit dry jointing system to provide gap free installation between the boards. The result is an even surface with optimal shock protection, counteracting injuries when running, landing or falling during intense activity.
Features and benefits:
- 28 mm low finished floor height.
- Factory finished, UV cured lacquer.
- Fully Sport England compliant.
- Can be uplifted and re-laid if required.
- Suitable for room sizes up to 400 m².
- PEFC® chain of custody certification available on ash species.
General information
Color | Brown Beige Other |
Finish | Lacquered |
Material | Timber Wood Foam High-density fibreboard (HDF) |
Length | 2250 mm |
Width | 190 mm |
Height | 28 mm |
Warranty description | 20 year |
Uniclass | |
CAWS | K21/10 Wood laminate flooring K21/111 Wood floating floor |
Specification data - Wood floating floor systems
System performance | Standards: Certified to EN 14904 - Area Elastic A3. |
Subfloor preparation layer | To conform to BS 8204-1:1987 and should not deviate more than 3 mm under a 2 m straight edge, having a suitable damp proof membrane. |
Vapour control layer | One layer of 1200-gauge slip membrane to be installed on top of cementitious base.Guidance for specification option: Damp proof membrane may be required dependant on site readings. |
Underlay | Resilient foam and spring fixed to the underside of the board.Guidance for specification option: For energy absorption. |
Flooring | |
Board type | 190 x 2250 x 28 mm prefinished three ply engineered boards with 3.6 mm nominal hardwood wear surface.Guidance for specification option:
|
Jointing | Woodloc® smart-fit dry jointing system. |
Perimeter flanking seal | Proprietary supports are to be utilised around the perimeter and around any obstructions. |
System accessories | None.Access bushings.Carpet tile floor protection.Sports skirting.Door threshold trims.Sports line marking and logos. |
Samples required | Manufacturer guidanceSamples are available; insert requirements or omit. |
Third-party certification | Not required. PEFC. Guidance for specification option: PEFC® Chain of Custody Certification is available on Ash species. |
Surface finish | Factory applied sports lacquer adhering to EN 2813. Specular gloss >45. |
Sustainability data
Contains Red List materials | No |
Country of material origin | Europe |
Country of product manufacture | Europe |
Material | Timber Wood Foam High-density fibreboard (HDF) |
BIM objects
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
| Platform | Compatible | Version |
|---|---|---|
 Revit | - | 1 |
 IFC | - | 1 |
Third party certifications
Chain of Custody Certification
PEFC Chain of Custody Certification
Literature
Reflex ActiveFloor
