Acoustic Sports Wall Panel

Verified by manufacturer 2 months ago

DYNAMIK Sports Flooring Third party certifications:
  • FSC

    FSC

    Certificate type

  • QA Certificate

    QA Certificate

    Certificate type

Acoustic (Perforated) Sports Wall Panels for sports halls, arenas, stadiums, leisure centres, and fitness spaces, fire rated, achieves Class A acoustic performance whilst being high impact resistant.

Jump to:
BOS
+44 (0)117 301 5120 Website

Application

  • Suitable for use in sports hall environments
  • Insulation must be placed behind the perforated panels to achieve required acoustic values (consult the manufacturer for details).
  • A minimum void of 50mm is required behind perforated panels to achieve Class A acoustic performance.
  • The substrate consisting of vertical studwork or a supporting structure must be free of flex and movement.
  • The panels are typically fixed to timber horizontal battens at 400mm centres which are packed level without undulation or steps.
  • Panels are installed using the supplied secret clips to ensure a consistent 7mm spacing between adjoining panels.
  • The secret clips must be fully supported by the horizontal battens.
  • The secret clips are to be placed into the pre-routed edges to leave the appearance of a fixture-free installation.
  • The relevant fixing for the substrate must be used.

Description

The DYNAMIK Acoustic (Perforated) Sports Wall Panels can ensure you meet current design requirements as set out by Building Regulations (within Building Bulletin 93) and current Sport England guidance with regards to sound absorption.


Features and benefits:

  • Designed to meet current design requirements as set out by Building Regulations (within Building Bulletin 93) and Sport England guidance concerning to sound absorption.
  • Durable and impact resistant; can be combined with Solid Wall Panels from floor to soffit, creating a flush wall finish.
  • Developed specifically for busy and demanding sports hall environments.
  • Achieves Class A acoustic performance; insulation must be placed behind the perforated panels to achieve required acoustic values with a min. void of 50mm.
  • Provides impact resistance from balls, equipment and hall users.
  • Fast and efficient installation with unique secret fixings.
  • Fire rated to European Class B-S1-d0.
  • Available in wood effect finishes or solid colour to compliment sports floor and achieve the required Light Reflective Values (LRVs).
  • Can be combined with matching Solid Sports Wall Panels in a range of colours that complement the sports floor to give you a complete solution for the internal finishes of the sports hall and create an aesthetically pleasing environment.
  • Panels can be fixed to metal or timber studwork at 400mm centres.


System includes:

  • 18 mm plywood or MDF panels finished with a melamine laminate and routed around all edges.
  • Black secret fixing clips designed to sit in the routed edges to provide a consistent 7 mm spacing between panels.
  • Panels supplied standard size (length: 2400 mm; height 1200 or 592 mm).
  • Black acoustic shadow membrane to sit behind panels and fixings.
  • MDF fire-rated to Class B-s1,d0.
  • Plywood to be FSC certified.
  • SUPPLY & FIX AVAILABLE BY DYNAMIK

General information

Color

Manufacturer guidance

Available in a range of colours or wood effects, consult manufacturer for details.

Finish

Laminated

Manufacturer guidance

Every panel is factory finished with a low maintenance, durable surface that does not require re-finishing over the life of the product.

Material

Wood

Guidance for specification option:

Engineered board core with a CPL laminated surface finish.

Shape

Rectangle

Length

2400 mm

Width

576 mm

Height

16 mm

Guidance for specification option:

Thickness.

592 mm

1200 mm

Uniclass

Ss_25_25_45_70 Rigid sheet wall lining systemsPrimary

CAWS

K13/160 Proprietary

K13/170 Acoustic panel lining

Specification data - Rigid sheet wall lining systems

Support

Rigid SFS or batten framework at 400 mm vertical centres.

Insulation

50 mm insulation required behind perforations for acoustic performance Class C.

Fasteners

Secret clip fixings direct to SFS or batten framework.

Colour

Anthracite.

Ash.

Bavarian Beech.

Beau Oak.

Birch.

Show more

FireRating

Class B-s1,d0.

Sustainability data

Country of material origin

United Kingdom

Material

Wood

Guidance for specification option:

Engineered board core with a CPL laminated surface finish.

Expected Life

25 year
