Fire resistant interior wood cladding for acoustic treatment.
Suitable for interior walls and ceilings that require a specific level of sound absorption such as conference rooms, auditoriums, classrooms and theatres.
Please note that due to the fact that wood is a natural product, each veneer may have colour and structure differences. Singularities such as knots and resin inclusions are not considered as defects. There are differences in light fastness performances depending on the wood species and the source of the wood - consult manufacturer for further details.
Highly resistant and tough natural wood cladding for internal walls and ceilings that require specific sound absorption characteristics. It is available in 15 wood species and the surface has a slight satin appearance, providing the physical sensation of the grain and knots in the original wood veneer.
Construction:
Features and benefits:
Applications:
Suitable for interior walls and ceilings that require a specific level of sound absorption such as conference rooms, auditoriums, classrooms and theatres.
Please note that due to the fact that wood is a natural product, each veneer may have colour and structure differences. Singularities such as knots and resin inclusions are not considered as defects. There are differences in light fastness performances depending on the wood species and the source of the wood - consult manufacturer for further details.
Size | 600 x 600 mm 1200 x 600 mm 1200 x 1200 mm 2440 x 600 mm 2440 x 1220 mm |
Uniclass 2015 | |
CAWS | K13/160 Proprietary K13/170 Acoustic panel lining |
Product Reference | Acoustic F |
Size | 600 x 600 mm1200 x 600 mm1200 x 1200 mm2440 x 600 mm2440 x 1220 mm |
Thickness | 12 mm18 mm |
Species/ Colour | American oakCaramel bambooCountry oakEucalyptusGraphiteMapleNatural bambooNatural beechOlivier ashReconstituted grey oakRustic oakSand oakSmoked grey oakTeakWalnut |
Slots/ perforations | 16.25 mm perforation spacing32 mm vertical slot spacing32.5 mm perforation spacing64 mm vertical slot spacingStaggered perforation spacing |
Antibacterial coating | Not requiredRequired |
Fixing | Hidden fixing with adhesive systemFor walls. Hidden fixing with plugsFor walls and ceilings. Hidden slats systemFor ceilings. Removable clip systemFor walls. Removable system with Velcro FastenerFor walls. |
Accessories | Insert requirements, consult manufacturer's literature for information. |
Standard product features | Technical characteristics:
|
