Access A or C


Designed for corridors or areas with service installations in the ceiling void where frequent access is required.


The Access range of ceiling systems consists of Access panels and the Connect Access grid, designed for corridors or areas with service installations in the ceiling void where frequent access is required. The system is arranged in rows, with a 23 mm space between individual panels, and is mounted wall-to-wall, with or without margins.

In large areas, the Access system can be installed in rows to create a grid pattern.

Components of suspension system:

  • Wall brackets for wall junctions and for one-piece panels across the full width of the corridor.
  • Double-carrier profile for adjacent rows of panels.
  • Transition profile for junctions with suspended ceilings, Access frieze panels or plasterboard margin.
  • Perforated suspension bars and brackets.
  • Space between panels: 23 mm (side to side), 20 mm between panel and transition profile at each end.
  • The sound-absorber panels are framed on all sides with a white, painted steel channel.

Features and benefits:

  • The tiles are manufactured from high-density glass wool.
  • The visible surface has an Akutex™ FT coating, and the back of the tile is covered with glass tissue.
  • The simple suspension system allows the panels to be easily lowered from either side, allowing the panels to drop down with a hinge effect.
  • The panels can be opened fully in long 'lanes' for servicing and other work.
  • There are no cross-suspension components.

General information


Akutex FT – the surface allows almost 100% of the sound energy to penetrate into and be absorbed by the glass wool. Painted edges


Wide range available.



High-density glass wool





Full warranty available upon request

Uniclass 2015

Ss_30_25_22_90 Unit/ modular suspended ceiling systemsPrimary


K40/10 Suspended ceilings

K40/105 Suspended ceiling system

K40/115 Unit/ modular suspended ceiling system

K40/265 Infill units

K45/12 Existing suspended ceiling system

K45/120 Existing suspended ceiling system

K45/13 Suspended ceiling system alterations

K45/130 Unit-suspended ceiling system alterations

K45/160 Board-suspended ceiling system alterations

Specification data - Unit/ modular suspended ceiling systems Enhanced data

Ceiling support

Connect™ access grid.

Support fasteners

Wall brackets for wall junctions and for one-piece panels across the full width of the corridor, perforated suspension bars and brackets.

Ceiling units

High-density glass wool tiles.

System accessories


Access 0147 wall brackets at 1800 mm centres.

Access 0151 transition profile at junctions with suspended ceilings.

Access frieze panels.

Product Reference

Access A

27 mm panel thickness, 80 mm demounting depth, 120 mm overall system depth (minimum), square-edged.

Access C

37 mm panel thickness, 90 mm demounting depth, 130 mm overall system depth (minimum), bevel-edged.


577 mm.

600 mm modular.

1177 mm.

1200 mm modular.


Insert requirement, available 560–2000 mm.

Colour/ Finish

Cloudy Day.

Nearest NCS colour sample S 1500-N, 62% light reflectance.

Dark Diamond.

Nearest NCS colour sample S 9000-N, 4% light reflectance.

Eucalyptus Leaf.

Nearest NCS colour sample S 5010-B30G.

Fresh Clover.

Nearest NCS colour sample: S 3020-G40Y Light reflectance: 35%.

Goji Berry.

Nearest NCS colour sample S 3030-Y80R.

Show more


4 kg/m².

approximate, including Connect grid system

Indoor climate

Recommended by the Swedish Asthma and Allergy Association. Certified as A+ by French VOC. Emission classification of building materials M1.

Moisture resistance

Tested in accordance with EN 13964, and can withstand a permanent ambient relative humidity of up to 95% at 30°C without sagging, warping or delaminating.

Fire safety

To BS EN 13501-1, Class A2-s1, d0.

Sound absorption

200 mm-deep system: in accordance with EN ISO 11654, Class A.


Panels hinge downwards for full access.


The ceiling system can withstand daily dusting and vacuum cleaning, and weekly wet-wiping.

Environmental information

Contains Red List materials

All Ecophon products are free from substances of very high concern (SVHC) and any compound on the list of REACH in the EU.


Country of material origin


Embodied carbon

No performance declared

Recycled content
