44 mm Thick Acoustic Timber Door In Microflush Frame
Verified by manufacturer 5 months ago
BM Trada
Certificate type
Single leaf timber doorset with acoustic core, customizable to meet project requirements.
Application
Suitable for office and workplace applications in a commercial sector environment.
Description
44 mm thick, single leaf doorset, featuring a solid acoustic core square-edged leaf in a high-quality veneered or spray-lacquered finish.
Features and benefits:
- Supplied with high-quality grade 1.4301 (304) stainless steel butt hinges.
- Available with a range of locking and handle options, including a threshold drop seal for optimum acoustic performance.
- Where an offset pivot is required, Optima’s stainless steel quad hinges can be used with floor springs or free-swing spindles.
- Part M compliant clear opening.
- Compatible with Optima’s entire range of glass partitioning systems.
General information
Color | Brown Silver White Other |
Finish | Veneered Lacquered |
Material | Timber Wood Aluminium |
Shape | Rectangle |
Width | Bespoke |
Height | Bespoke |
Warranty description | Ten year Guidance for specification option: This excludes installation, moving parts, ironmongery and fire rated glass which are covered elsewhere (see Optima policy document for more information). |
Uniclass | |
CAWS | L20/410 Wood doorsets L20/55 Doorsets |
Product range |
Specification data - Wood doorsets
Third party accreditation | BM Trada certified. |
Standard | To ISO 14001:2015 Environmental Management System and ISO 9001:2015 Quality Management System. |
Configuration | As drawing.Guidance for specification option: Insert drawing reference number. As schedule. |
Doorset size | Guidance for specification option: Available up to 3000 mm in height. Overall frame width: 986–1006 mm. Insert requirements or drawing reference number. |
Format | Single leaf, single action, non-rebated in Microflush frame. |
Performance | |
Acoustic performance | Up to 36 dB.Manufacturer guidanceAcoustic rating (Rw, maximum): |
Accessibility | Part M compliant. |
Frame | |
Material | Aluminium. |
Perimeter seals or inserts | Not required.Threshold drop seal.Guidance for specification option: Provides optimum acoustic performance. |
Finish | Anodized.Guidance for specification option: 25 microns thickness. Grained.Guidance for specification option: Brightened and protective anodized. Polished.Guidance for specification option: Brightened and protective anodized. Powder-coated.Guidance for specification option: Specify colour requirements below. |
Colour | Not required.Guidance for specification option: For anodized, grained and polished options (above). Colour, RAL.Guidance for specification option: Insert requirement; contact manufacturer for more information. Colour, RAL 9006 Silver.Guidance for specification option: 50 microns, 30% gloss (nominal). Colour, RAL 9010 White.Guidance for specification option: 50 microns, 30% gloss (nominal). Manufacturer guidancePowder-coated. |
Frame accessories | Manufacturer's standard.Guidance for specification option: High-quality grade 1.4301 (304) stainless steel butt hinges. Optima stainless steel Quad hinges.Guidance for specification option: Where an offset pivot is required. |
Door leaf | |
Thickness | 44 mm. |
Core | Solid core.Guidance for specification option: Acoustic. |
Panel details | Leaf width: 926 mm. |
Perimeter seals | Acoustic. |
Finish | Veneered.Guidance for specification option: Insert requirements. Spray lacquer.Guidance for specification option: Insert requirements. |
Glazing | |
Type | Not required.Required.Guidance for specification option: Insert requirements. As drawing.Guidance for specification option: Insert drawing reference number. As schedule.Manufacturer guidanceFor glazed system options refer to Optima 117 Plus literature or contact manufacturer for more details. |
Door accessories | Not required.Floor springs.Free swing spindles. |
Hardware | Guidance for specification option: Insert requirement; contact manufacturer for more information. |
Locking | Dead lock. Sash lock. Latch. |
Sustainability data
Country of product manufacture | United Kingdom |
Embodied carbonA1-A3 (production stage) as defined in BS EN 15804 | kg·CO₂e/kg Self declared Guidance for specification option: See Environmental Product Declaration literature for LCA data. |
BIM objects
| Platform | Compatible | Version |
|---|---|---|
 Revit | Revit 2016 | 1 |
Third party certifications
BM Trada
009109 (3) - ISO 14001 - Optima Products Limited
BM Trada
000016 (4) - ISO 9001 - Optima Products Limited
