Contemporary Hollow Decking (Hidden Clip Fixing System)

Application

Suitable for domestic and light commercial use.

Description

The contemporary composite decking range offers a long-lasting, hard-wearing product designed to outlive traditional timber alternatives.


Features and benefits:

  • Anti-slip properties.
  • High tensile strength.
  • Mould and fungus resistant due to low water absorption rates of 0.2%.
  • Boards will not warp or rot.
  • Hard wearing.
  • Low maintenance.
  • Splinter-free.
  • Easy to install.
  • Hidden fixings.
  • Matching trim available.
  • Square edge boards.
  • Can be used with solid boards for edging, steps etc.
  • Same product all the way through.
  • Approximately 90% recycled material.
  • 10-year warranty.


Accreditations:

  • Available as FSC® certified on request.
  • CE marked.
  • SGS test reports available, see manufacturer's literature for details.

General information

Finish

Dual sided: Deep grain embossed and mid-groove.

Embossed

Grooved

Color

Coffee, charcoal or grey.

Brown

Grey

Material

Wood-plastic composite (WPC)

Shape

Rectangular

Size

3600 x 143 x 23 mm

WarrantyDescription

Ten years

Ten-year warranty.

Uniclass 2015

Ss_30_20_30_25 Decking systemsPrimary

CAWS

Q55/110 Deck

Product range

Decking

Specification data - Decking systems Enhanced data

Structure

-

Subframe

Not required.

Aluminium Subframe for Composite Decking - Fire Resistant.

Aluminium Subframe for Composite Decking - Non Fire Resistant.

Deck boards

-

Material

Wood-plastics composite deck boards.

Fasteners

Hidden clips.

Guarding

Not required.

Edge protection

Not required.

System accessories

Cross recess M4 x 25 mm.

Hollow fixing clip.

Joining clip.

Start-up clip.

Trim board.

70 x 10 x 2200 mm. Can be used for decorative edging in light traffic areas.

Board colour

Coffee.

Charcoal.

Grey.

Weight

10 kg.

Per board.

TensileStrength

at 400 mm centres.

31.2 MPa.

Slip resistance

To BS 7976-2:2002+A1:2013, mid-groove: 59 dry, 45 wet; deep grain: 47 dry, 38 wet.

Product Reference

Contemporary Hollow Decking (Hidden Clip Fixing System)

Flexural strength

43.4MPa.

300mm centres.

45.1MPa.

350mm centres.

43.2MPa.

400mm centres.

Environmental information

Country of material origin

China

Country of product manufacture

China

Recycled content

90

Approximately 90% recycled materials consisting of around 60% recycled wood fibres, 30% recycled plastic and 10% toxin free additives including colour and UV stabilisers.

Literature

Hollow Mid-Groove Test Report

Hollow Mid-Groove Test Report

Third party certifications

QA Certificate

QA Certificate

QA Certificate

QA Certificate
