Summary
Range of flow restrictors for controlled rainwater drainage on blue roofs by the targeted reduction of water intake.
-
-
Application
For delayed rainwater drainage with a retention roof.
-
-
Description
Range of retainers for controlled rainwater drainage by the targeted reduction of water intake.
Features and benefits:
- For use in conventional drainage outlets for targeted reduction of water intake.
- Optionally with or without dome grate depending on application.
- Simple insertion in the outlet pot without extra tools.
- With scaled adjusting slide or predefined opening.
- For controlled rainwater drainage.
- Emergency drainage elements are a noticeable yellow.
- Compatible with a range of Sita products: SitaStandard*; SitaIndra**; SitaMulti**; SitaTrendy*; SitaSani®*.
*Specified separately.
**Consult manufacturer for details.
-
-
Product certifications
- TUV - Safety and Quality Report LGA Certification - EN 1253-2:2015
-
-
Digital objects
-
-
Color
Silver, Beige, Black, Yellow
-
-
Material
Polyurethane (PUR), Aluminium, Rubber, Polyamide, High density polyethylene (HDPE), Polyethylene
-
-
Shape
Square, Circle
-
-
Length
151 mm, 153 mm, 194 mm, 196 mm, 310 mm, 320 mm, 328 mm, 400 mm, Bespoke
-
-
Width
151 mm, 153 mm, 194 mm, 196 mm, 310 mm, 320 mm, 328 mm, 400 mm, Bespoke
-
-
Height
120 mm, 207 mm, 253 mm, 307 mm, 432 mm, 600 mm, Bespoke
-
-
Warranty description
Six year
-
-
SKU Code
409103, 409104, 409201, 409203, 409202, 409204, 233040, 234040, 109175, 109176, 109177, 159175, 159176, 159177
-
-
Specification
Classification data
Material
Polyurethane base.
-
-
Grating
Flat; 400 x 400 mm, mesh size 9 x 32 mm; hot-dip galvanized.
-
-
Integral accessories
Height-adjustable rubber feet
-
-
Additional properties
Accessories
None., SitaGreen extension unit.
-
-
Dimensions
400 x 400 x 100–120 mm.
-
-
Sustainability data
Country of material origin
Germany
-
-
Country of product manufacture
Germany
-
-
Material
Polyurethane (PUR), Aluminium, Rubber, Polyamide, High density polyethylene (HDPE), Polyethylene
-
-
Carbon dioxide equivalent
Normalized unit
(kg CO₂ eq/kg) A1–A3 ('Production stage') :
-
A1–A3 ('Production stage') :
-
A1–A3 ('Production stage') :
-
Declared unit
Certified
A1–A3 ('Production stage') :
13.4
Certified
A1–A3 ('Production stage') :
-
Certified
A1–A3 ('Production stage') :
-
