Case study - heavy duty pipe supports

OVERVIEW

We were approached to help design the support system for two new district heating pipelines running under a newly constructed bridge spanning the River Avon.

There were several complexities on this project including the heavy pipework, pipe expansion, corrosive environment and vibrations.
