VEGA 1500 Series Riser Doors - Non Fire Rated
Verified by manufacturer 1 month ago
VEGA 1500 Series Riser Doors NFR - Single door
VEGA 1500 Series Riser Doors NFR - Single door
ISO 9001 Quality Management
Certificate type
A non-fire-rated riser door, manufactured and tested to meet standards suitable for a wide range of non-fire rated market applications.
Application
Suitable for use within student halls of residence, care homes and hotels.
Description
Quick release, light weight, engineered riser doors supplied with adjustable frames that require no packers for simple, faster and safer installations.
Single or double, quick release, light weight door configurations, including lock and frame options to suit finishing requirements, can be supplied.
Features and benefits:
- Fast and simple to install.
- Quick release pivot hinge with retractable flush bolt.
- Hinge pin for easy positioning and door alignment.
- Light weight door for easy handling.
- Single door and double door configurations.
- Fully recyclable at end of life.
General information
Color | White Guidance for specification option: RAL 9010. Other Guidance for specification option: Any RAL colour available on request. |
Finish | Matt Powder-coated |
Material | Carbon steel Guidance for specification option: Electro-galvanized. |
Shape | Rectangle |
Width | 938 mm Guidance for specification option: Maximum door leaf width, suitable for 2493 mm height. 1035 mm Guidance for specification option: Maximum door leaf width, suitable for 2750 mm height. Manufacturer guidanceUnequal width double leaf dooresets are also allowable, provided that the secondary leaf shall have a minimum width of 350 mm, and shall be a minimum of 40% the width of the primary leaf. |
Height | 2750 mm Guidance for specification option: Maximum door leaf height, suitable for 938 mm width. 2493 mm Guidance for specification option: Maximum door leaf height, suitable for 1035 mm width. Manufacturer guidanceUnequal width double leaf dooresets are also allowable, provided that the secondary leaf shall have a minimum width of 350 mm, and shall be a minimum of 40% the width of the primary leaf. |
Warranty description | Five year |
Uniclass | |
CAWS | L20/55 Doorsets L20/480 Doorsets K10/125 Metal stud partition system K10/215 Suspended ceiling system K10/220 Proprietary suspended ceiling system K10/155 Wall lining system (metal studs) K10/430 Access panels L20/630 Hatches K10/15 Lining on timber K10/30 Metal stud K10/115 Metal stud partition system K10/145 Wall lining system (metal studs) K10/165 Wall lining system (metal framing) K10/25 Ceiling lining on timber K10/50 Suspended ceiling system on metal framing |
Specification data - Carbon steel doorsets
Configuration | Single door (SD). |
Doorset size | 2750 x 938 mm.Guidance for specification option: Maximum door leaf height x suitable width. 2493 x 1035 mm.Guidance for specification option: Maximum door leaf height x suitable width. |
Performance | |
Fire resistance | |
Integrity | Non-fire rated (NFR). |
Acoustic performance | 31 dB (Rw). |
Frame | |
Material | Electro-galvanized mild steel. |
Perimeter seals or inserts | Acoustic, intumescent and smoke seal. |
Finish | |
Coating | Powder-coated.Guidance for specification option: Fully powder coated matt RAL 9010. |
Texture | Matt. |
Colour | White (RAL 9010).Guidance for specification option: Fully powder coated matt RAL 9010. RAL.Guidance for specification option: Suitable for finishing on site or other RAL colours available on request. |
Door leaf | |
Thickness | 1.2 mm. |
Material | Electro-galvanized mild steel door leaf, Rockwool core. |
Beading | |
Type | Beaded frame (BF).Guidance for specification option: Suitable for tape and jointing/ skimming. Picture frame (PF).Guidance for specification option: Suitable for retrofitting/ finished areas. |
Material | Steel. |
Fixing | Fully welded. |
Finish | |
Coating | Powder-coated. |
Texture | Matt. |
External colour | White (RAL 9010).Guidance for specification option: Fully powder coated matt RAL 9010. RAL.Guidance for specification option: Suitable for finishing on site or other RAL colours available on request. |
Door accessories | Acoustic, intumescent and smoke seal to frame. |
Collar | Stainless steel. White plastic. Guidance for specification option: Standard. Manufacturer guidanceLock. |
Weight | 17.5 kg/m². Guidance for specification option: Including frame. |
FrameDepth | 66 mm. |
Sustainability data
Contains Red List materials | No |
Country of material origin | Europe |
Country of product manufacture | United Kingdom Guidance for specification option: Britain. |
Recyclability | 98% |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 20 % Manufacturer guidance20–25% |
