TVS Quietstone Wall Panels

Name: TVS Quietstone Wall Panels
Brand: Total Vibration Solutions Limited t/a TVS Group
SKU: syjPAH3ahVqpH1UMz8upmW

Verified by manufacturer 2 months ago

Total Vibration Solutions Limited t/a TVS Group

Rigid, durable absorber made from recycled glass.

Jump to:

+44 (0)1706 260 220 Website

Application

Suitable for external use, indoor use and settings which require high impact resistance.

Description

TVS Quietstone Light is a rigid, durable absorber made from recycled glass. It can be worked on site, pigmented or treated with a range of finishes and is non-combustible, chemically inert and nanofibrous. Panels can be either mechanically fixed or bonded and a range of sizes are available including custom options.

Features and benefits:

High sound absorption.
Non-combustible.
Weather resistant.
Self-bearing.
Easily cut on site.
94% recycled glass.
Bespoke sizes available.

General information

Color	Other
Material	Glass
Shape	Rectangle
Length	Bespoke 1200 mm Guidance for specification option: Standard length. 2400 mm Guidance for specification option: Maximum length.
Width	Bespoke 600 mm Guidance for specification option: Standard width.
Height	15 mm Guidance for specification option: Minimum thickness. 100 mm Guidance for specification option: Maximum thickness. Bespoke

Uniclass	Pr_35_93_13_80 Sound attenuator infill unitsPrimary
CAWS	K13/170 Acoustic panel lining K13/170 Acoustic panel lining

Specification data - Sound attenuator infill units

Standard	To BS EN ISO 354:2003.
Form	Panel.
Rigidity	Rigid.
Application	Wall mounting.
Material	Recycled glass.
Material density	320 kg/m.
Acoustic performance	-
Purpose	Absorber.
Sound absorption	- Manufacturer guidance Consult manufacturer for details and insert requirements.
Fire performance	-
Fire resistance	To BS 85476 (Part 6:1989), Class 1 and BS 85476 (Part 7:1997), Class 0.
Dimensions	-
Size (length x width)	- Manufacturer guidance Standard length: 1200 mm. Maximum length: 2400 mm. Standard width: 600 mm. Insert requirements.
Thickness (overall)	15–100 mm. Guidance for specification option: Insert requirements.
Edges	Square.
Surface pattern	Solid.

Freeze/ Thaw Resistance	To EN 1338, Class 0.

Sustainability data

Contains Red List materials	No
Country of material origin	United Kingdom
Country of product manufacture	United Kingdom
Recycled content As defined in clause 7.8 of BS EN ISO 14021	94 % Guidance for specification option: Made from recycled glass.
