TUP Long Nylon Plug with Countersunk Pozi Screw
Verified by manufacturer 7 months ago
6 mm diameter
6 mm diameter
Range of countersunk, Pozidriv head, coated steel screws with matched long Nylon plugs.
Application
Suitable for connections into:
- Concrete.
- Solid stone.
- Solid brick.
Partially suitable for connections into:
- Honeycomb brick/ lightweight honeycomb brick.
- Hollow light aggregate block.
- Cell-like clay brick.
- Hollow dense aggregate block.
- Aerated concrete.
Description
Range of countersunk, Pozidriv head, coated steel screws with matched long Nylon plugs.
Features and benefits:
- Screws are white zinc-plated.
- Range of lengths and diameters.
- Suitable for use in a range of solid or hollow substrates.
- Some options also available with Torx or hex heads (specified separately).
The use of plastic anchors is not recommended for permanent suspended loading applications above 40°C.
General information
Color | Silver |
Material | Steel Nylon |
Shape | Other |
Length | 60 mm 80 mm 100 mm 120 mm 135 mm |
Width | 6 mm 8 mm 10 mm |
Uniclass | |
CAWS | Z20/340 Masonry fixings Z20/340 Masonry fixings |
Specification data - Framing fasteners
Screw material | Carbon steel, grade 5.8.Guidance for specification option: White zinc-plated ≥5 µm, to ISO 4042. |
Sleeve material | Nylon Pa6. |
Head arrangement | Countersunk; Pozidriv. |
Anchor length | 60 mm (60303B0606000).Manufacturer guidancePack size: 100. |
Thread diameter | 6 mm. |
