Trovex Stainless Steel

Verified by manufacturer over a year ago

Trovex

Stainless steel wall cladding.

Jump to:
+44 (0)1707 254170 Website

Description

Stainless steel sheets complementing the Trovex Diamond system in food preparation areas, making it easy to provide heat-resistant surfaces where required. Stainless steel splashbacks are recommended for use directly behind a cookline, due to the high temperatures involved. The system marries with Trovex hygienic wall cladding and can be joined directly to the PVC sheets.

Suitable substrates:

Concrete blockwork/ plaster board.

General information

Material

Stainless steel grade 1.4301 (304)

Uniclass

Ss_25_25_75_85 Specialist faced panel lining systemsPrimary

CAWS

K13/160 Proprietary

Product range

Hygienic Wall Cladding

Specification data - Specialist faced panel lining systems

Product Reference

Trovex Stainless Steel

Sheet

-

Sheet size (l x w)

2000 x 1000 mm

2500 x 1250 mm

Sheet thickness

0.7 mm

0.9 mm

1.2 mm

Adhesive

TB300/25

Jointing

Silicone joints

Guidance for specification option:

3–4 mm wide.

Accessories

None

Low profile jointing profile

Transition profile

Standard product features

Material:

Stainless steel grade 1.4301 (304).
