Triton TT Swellmastic S2 - Hydrophillic Waterstop and Adhesive
Verified by manufacturer 10 months ago
A grey, elastomeric, water-swellable paste which is applied like a sealant.
Application
Can be used as an adhesive for bonding waterbars or as a problem-solving hydrophilic waterstop in difficult access areas including:
- Sealing around joints in precast manhole covers, cable ducts and pipes etc.
- Sealing around precast segments.
- Sealing between rough surfaces eg slurry walls and concrete slabs.
- Sealing around H-beams and other penetrations through concrete structures.
- Sealing around conventional rubber and plastic waterstops to provide ‘belt and braces’ seal prior to concrete pour.
Description
A grey, elastomeric, water-swellable paste which is applied like a sealant. The hydrophillic properties display good consistency in swell rate during repeated wet/ dry cycling. Expansion of the product on contact with water creates a positive pressure against the faces of the concrete joint, thus preventing the passage of water.
Features and benefits:
- Fast curing: Enables early concete pour and rapid return to service. Allows hand-applied concrete cover within 2 hours on emergency repairs and large-scale concrete pour after 8 hours.
- Seal on rough concrete: Gives improved water tightness. Plugs inequalities in rough concrete to produce a tight seal.
- Adhesion: Quick and easy to apply to a variety of uneven joint surfaces remaining firmly in place during concrete pour.
- Water swellable: Expands by 200% producing a watertight compression seal.
- Durable: Excellent wet/ dry cycling retaining elastomeric character and swelling performance due to high tolerance of the cementitious environment.
General information
Color | Grey |
Material | Solvent-based Guidance for specification option: Elastomeric, water-swellable paste. |
Shape | Formless Guidance for specification option: Liquid. |
Length | Manufacturer guidancePer 600 mL pack:
|
Width | Manufacturer guidancePer 600 mL pack:
|
Uniclass | |
CAWS | E40/530 Sealant |
Product range |
Specification data - Construction joint sealants
Material | Elastomeric, water-swellable paste. |
Colour | Grey. |
Swelling capability | 200 %. |
Size: | Supplied in boxes of 10 x 600 mL sausage packs. Guidance for specification option: Per 600 mL pack:
|
Curing time | 3 mm in 24 hours. Guidance for specification option: Concrete pour: Allow between 2–8 hours (see application instructions). |
Shore A hardness | 10–15. |
Tack free time (hours at 23°C and 60% Relative Humidity (RH)) | Approximately 1 hour (at 20°C/ 50% RH). |
Sustainability data
Material | Solvent-based Guidance for specification option: Elastomeric, water-swellable paste. |
Literature
TT Swellmastic
