Application

High traffic public areas within the commercial, educational, hospitality, infrastructure, residential and retail industry sectors.

Description

A parametric, modular, phenolic wall lining system. Comprising of solid grade laminate panelling and a self-healing steel frame.

Available in both standard and ASIAD approved system versions.

Benefits:

  • For interior and exterior cladding application.
  • Waterproof and high impact resistance; suitable for high-traffic or wet areas.
  • Antibacterial properties.
  • A simple, quick and cost-effective solution.
  • Range of performances, textures and finishes available.

Components:

  • Galvanized steel supports, with self healing properties.
  • Concealed fixing hardware.
  • Universal and panel-hanging brackets.
  • Precision-machined panels.
  • Steel vertical uprights.
  • Joining sleeves.

Applications:

High traffic public areas within the commercial, educational, hospitality, infrastructure, residential and retail industry sectors.

General information
Specification data
Product Reference

Traffic|Wall® Phenolic

Thickness

10 mm

12 mm

18 mm

Colour/ Finish

A large range is available. Consult manufacturer and insert requirements.

Foot detail

Adjustable feet

Skirting

ProductInformation

www.inspiredsurfaces.com

Standard product features

Fire certification:

Self-healing steel is fire-rated as standard.

Horizontal rail length:

2800 mm.

Battens:

Standard steel sections.

Corner detail:

Internal, External and End Cap Arrangements.

Flash gap detailing:

Double-sided tape and flash gap strips.

Product Options

Material:

Available fire-rated. Consult manufacturer for information.

Digital objects
PlatformCompatibleVersionCertified to
Revit
Revit 2016 4 2.0
IFC
- 3 1.3
Download now from NBS National BIM Library
