Tiny Stuff SGL Panel Cubicle

Description

Tiny Stuff SGL is a washroom cubicle secured with sturdy floor and wall channels to ensure stability. Available with anti-finger trap hinges as standard and optional magnetic door catches, Tiny Stuff cubicles are available in two cubicle styles and partition heights, perfect for nursery and infant school children.

Panels are manufactured to specific site dimensions and CAD drawings will be supplied with each delivery.

Components:

  • Solid grade laminate panels, supplied with polished black radiused edges.
  • Frame comprising: Pilaster, legs, hinges and channel.

General information

Uniclass 2015

Ss_25_12_60_60 Panel cubicle systemsPrimary

CAWS

K32/10 Panel cubicles

K32/120 Panel cubicles

Product range

Cubicles

Specification data - Panel cubicle systems

Product Reference

Tiny Stuff SGL Panel Cubicles

Frame

-

Hinge & Channels colour

Charcoal grey

Powder coated aluminium.

Silver

Powder coated aluminium.

Legs & Headrail colour

Charcoal Grey

Powder coated aluminium.

Silver

Powder coated aluminium.

Yellow

Powder coated aluminium.

Red

Powder coated aluminium.

Blue

Powder coated aluminium.

Green

Powder coated aluminium.

Pilaster Foot colour

Charcoal Grey

ABS.

Silver

ABS.

Yellow

ABS.

Red

ABS.

Blue

ABS.

Green

ABS.

Doors

-

Height

1055 mm

Including 105 mm floor clearance.

1255 mm

Including 105 mm floor clearance.

Colour

Refer to manufacturer's standard colour range.

Lock

Magnetic door catch

ABS.

Charcoal Grey

ABS.

Silver

ABS.

Yellow

ABS.

Red

ABS.

Blue

ABS.

Green

ABS.

Shape (see manufacturer's guidance)

Angled

Curvy

Pilaster

-

Shape (see manufacturer's guidance)

Arrowhead

Crescent

Colour

Refer to manufacturer's standard colour range.

Accessories

None

Other requirements

None

Stylex printed doors

Standard product features

Panel Material:

  • Solid grade laminate, 1400 kg/m³.
  • Thickness (overall): 13 mm.
  • Edge detail: Polished black radiused edge.

Floor Clearance:

105 mm.

Hinges:

Continuous hinges with anti finger trap feature.

Partitions:

Straight cut to door height.

Pilaster Height:

1350mm.

Product Options

Colours:

- Panels: 36 laminate options and 4 digital prints - select from manufacturer's literature.

Door & Pilaster Shape:

- If the angled door shape is selected, the arrowhead pilaster must be used; if the curvy door is selected, the crescent pilaster must be used.

Accessories:

- Selection of soap dispensers, paper towel dispensers, toilet roll holders, hand dryers, coat hooks and door handles - select from manufacturer's literature.
