Thermowood (Redwood) Cladding

Thermowood (Redwood) Cladding

Millworks Ltd Third party certifications:
  • QA Certificate

    QA Certificate

    Certificate type

Using the finest Scandinavian Redwood which is an attractive dark brown, durable and perfect for external Cladding and Decking applications.

Jump to:
+44 (0) 1223 967723 www.millworks.co.uk

Application

Suitable for use on a range of external building projects.

Please note that the product will weather to a silver-grey if left untreated.

Description

PEFC™ certified Thermowood (Redwood softwood) cladding. Carefully selected from leading Finnish sawmills.

Features and benefits:

  • Available in a wide range of configurations.
  • Stable and durable.
  • Has a natural dark-brown appearance which provides an aesthetically pleasing, consistent aesthetic.
  • Tight, sound knots.
  • Heat treated in a unique gradual modification process, reaching temperatures of 212°C. This alters the chemical and physical properties within the wood, and causes a resistance to fungi.
  • Unlikely to warp or twist due to the inability to absorb or lose moisture (caused from the thermal modification process).
  • Low moisture content, which helps the wood to achieve a smooth finish when machined.
  • Service life of over 30 years.
  • PEFC™ certified.
  • Durability class 2 according to BS EN 350-2.

Applications:

Suitable for use on a range of external building projects.

Please note that the product will weather to a silver-grey if left untreated.

General information

Finish

Consult manufacturer for available finishes and insert requirements.

Color

Dark brown

Material

Timber

Shape

Rectangle

Size

19 x 5100 x 143 mm

Uniclass 2015

Pr_25_71_97_84 Softwood weatherboardsPrimary

CAWS

H21/10 Vertical timber weatherboarding

H21/110 Vertical timber weatherboarding

H21/111 Horizontal timber weatherboarding

H21/115 Vertical timber weatherboarding

H21/116 Horizontal timber weatherboarding

H21/15 Horizontal timber weatherboarding

Product range

Cladding

Specification data - Softwood weatherboards

Product Reference

Thermowood (Redwood) Cladding

Type

-

Grade

Sawfalling

Profile

MW-1

MW-2

MW-2 II

MW-3

MW-4

MW-5

MW-6

MW-7

MW-10

Finish

Consult manufacturer for available finishes and insert requirements.

Trims

Not required

19 x 43 mm

19 x 93 mm

19 x 143 mm

Fire retardant treatment

Not required

Fire retardant treatment (FRX Exterior)

Complies with the National Building Regulations where Euroclass B or C fire performance is required.

Fire retardant treatment (HR-Prof)

Complies with Euroclass B or C for spread of flame, and offers a quicker, cheaper option.

Standard product features

Density:

420 kg/m³.

Recommended fixings:

Stainless-steel cladding fixings should be used (natural oils in the timber have a corrosive effect on ferrous metals). Consult manufacturer for further details.

Product Options

Type:

- Profile:

See manufacturer's literature for profile diagrams/ visual differentiations.

MW-1:

  • Fixing: Face fixed.
  • Orientation: Vertical or horizontal.
  • Finish: Factory finished (insert requirement above).
  • Width: 93 mm or 143 mm (insert requirement above).
  • Thickness: 19 mm.

MW-2/ MW-2 II:

  • Fixing: Secret fix.
  • Orientation: Vertical or horizontal.
  • Finish: Factory finished (insert requirement above).
  • Width: 93 mm or 143 mm (insert requirement above).
  • Thickness: 19 mm.

MW-3/ MW-4:

  • Fixing: Secret fix.
  • Orientation: Horizontal.
  • Finish: Factory finished (insert requirement above).
  • Width: 93 mm or 143 mm (insert requirement above).
  • Thickness: 19 mm.

MW-5:

  • Fixing: Secret fix.
  • Orientation: Vertical or horizontal.
  • Finish: Factory finished (insert requirement above).
  • Width: 93 mm or 143 mm (insert requirement above).
  • Thickness: 19 mm.

MW-6:

  • Fixing: Face fixed.
  • Orientation: Vertical or horizontal.
  • Finish: Factory finished (insert requirement above).
  • Width: 44 mm, 70 mm, 93 mm, 143 mm or 193 mm (insert requirement above).
  • Thickness: 19 mm.
  • Can be used as cladding or trim board.

MW-7:

  • Fixing: Face fixed/ secret facade clip.
  • Orientation: Horizontal.
  • Finish: Factory finished (insert requirement above).
  • Width: 93 mm or 143 mm (insert requirement above).
  • Thickness: 19 mm.

MW-10:

  • Fixing: Face fixed.
  • Orientation: Horizontal.
  • Finish: Factory finished (insert requirement above) with planed face as standard.
  • Width: 143 mm (manufacturer's standard).
  • Thickness: 19 mm.

Please note that when the overall width is, for example, 143 mm, the exposed face size will be 125 mm.

Board size:

Insert width as indicated above. Consult manufacturer for details on available lengths.

Colour/ Finish:

Coatings provide ultraviolet (UV) protection. Boards are coated to all four sides for increased durability and stability.

Consult manufacturer for further guidance.

Fire retardant treatment:

- Fire retardant treatment (FRX Exterior):

Applied under controlled conditions in a vacuum pressure timber impregnation plant.

- Fire retardant treatment (HR-Prof):

Can be applied on-site.

Digital objects

Platform Compatible Version Certified to
IFC
-

1

2.1
Revit
-

1

2.1
Download now from NBS National BIM Library

Third party certifications

  • PEFC™: Certificate: PEFC/16-37-2002
