NBS Source
I'm a manufacturer

Application

Internal flooring, wall tiling.

Description

Single layer, slimline terrazzo tiles.


Features and benefits:

  • Manufactured to BS EN 13748-1&2: 2004.
  • High density (2.44 t/m³).
  • These tiles allow for reduced thickness in larger modules.
  • Suitable for overlaying floors in existing buildings and new construction where reduced dead loads are required.
  • Meets HSE recommendations for low slip potential in dry environments.
  • Can be monolithically bedded on cement and sand or fixed in adhesive.
  • Easy to maintain.
  • Case hardener (impregnator) can be factory applied reducing site operations thus speeding up installation.
  • Typical design life is 30 years plus.

General information

Color

Black

White

Grey

Silver

Beige

Show more

Finish

Honed

Material

Terrazzo

Various marbles and cement.

Shape

Square

Rectangle

Length

400 mm

600 mm

300 mm

Width

298 mm

400 mm

600 mm

Height

18 mm

22 mm

WarrantyDescription

Consult manufacturer for details.

-

Uniclass

Pr_35_93_96_90 Terrazzo tilesPrimary

CAWS

M41/110 Terrazzo tiling

M41/110 Terrazzo tiling

Specification data - Terrazzo tiles

Standard

-

Internal use

To BS EN 13748-1.

External use

To BS EN 13748-2.

Finish

Honed.

Colour

Isernia

Lava

Fusion

MG09

Creda

1.13.3.2008.2B

10.11.20

City

V14

Skyline

New Steel

Erna

Forest

Carbi

Carrara

Bespoke

Minimum order quantities apply; consult manufacturer for details.

Sizes

Conforms to BS EN 13748‐1: 2004 requirement (±0.3 mm).

400 x 400 mm.

600 x 600 mm.

600 x 298 mm.

Thickness

Conforms to BS EN 13748‐1: 2004 requirement (±2.0 mm).

18 mm.

400 x 400 mm only.

22 mm.

600 x 600 mm or 600 x 300 mm.

Weight (maximum)

Dependent on Thickness specified, for reference only.

45 kg/m².

18 mm-thick.

55 kg/m²

22 mm-thick.

Slip potential

-

Slip resistance value (SRV) / Pendulum test value (PVT) (minimum)

-

Requirement

≤35.

PTV.

Water absorption (maximum)

0.19 g/cm².

To BS EN 13748‐1: 2004.

Water absorption to the whole tiles: 4%.

Breaking strength:

7.0 MPa.

To BS EN 13748‐1: 2004.

Load capacity

3.08 kN.

To BS EN 13748‐1: 2004.

Abrasion resistance

Less than 25 mm – Modified Capon Test.

To BS EN 13748‐1: 2004.

Reaction to fire

Class A1.

Without testing.

Environmental information

Country of material origin

Europe

Country of product manufacture

Europe

Recyclability

100%

Recycled content

40 %
