Sylpro Underlay Acoustic Insulation - Resilient layer

Name: Sylpro Underlay Acoustic Insulation - Resilient layer
Brand: Buildtec Acoustics
SKU: eTu6hNEFpMo8marX5moQTN

Verified by manufacturer 4 months ago

Sylpro 3

Buildtec Acoustics

Resilient Layer Insulation - Acoustic underlay in roll format, designed for a range of applications.

Jump to:

07570 848 410 Website

Application

Resilient layer underlay acoustic insulation designed for reduced thickness floors. Can be used under parquet, laminate, wood, carpet and ceramic tiles as well as under linoleum and PVC flooring. Can also be used on floors with floating screeds, and as an isolator.

Description

Resilient layer acoustic underlay designed to absorb noise (including footfall and other types of impact noise).

Available in five thickness options.

Features and benefits:

VOC Free.
Noise reduction: No acoustic degradation over time.
Easy to install - allows for dry or glued laying depending on the application.
High density.
High mechanical resistance.
High stability, and castor proof.
Suitable for use with underfloor heating.
Impact sound reduction of up to 22 dB.
Tested to comply with Irish and UK Building Regulations.
Suitable under Tile, Wood Floor, Laminate & LVT.

General information

Color	Black
Finish	Textured
Material	Styrene-butadiene rubber (SBR) Polyurethane
Shape	Rectangle
Length	6000 mm 8000 mm 10000 mm 20000 mm
Width	1250 mm
Height	3 mm 5 mm 6 mm 8 mm 10 mm
Warranty description	Other

Uniclass	Pr_25_57_06_71 Resilient layer insulationPrimary
CAWS	M50/15 Carpet tiling M50/130 Carpet tiling M42/120 Mosaic parquet panel flooring M40/5 Tiling to M40/110 Tiling to M10/295 Floating construction (thin sheet impact sound insulation) K21/115 Wood laminate flooring K21/111 Wood floating floor K21/110 Wood flooring K11/275 Acoustic separating floor system M42/10 Wood flooring K11/27 Acoustic separating floor system K21/10 Wood laminate flooring M10/40 Floating construction

Specification data - Resilient layer insulation

Material	SBR fibre. Guidance for specification option: Hot compacted using a polyurethane binder.
Density	730 kg/m³.
Thickness	3 mm.
Fire performance	Reaction to fire classification: Class E.
Sound insulation rating	≥19 dB sound insulation.

Weight	2.19 kg/m².
Dynamic stiffness	≤77 MN/m³.
Compression strength	≤0.2 mm. Manufacturer guidance Compressibility.
ThermalConductivity	0.12 W/m·K.
Impact sound reduction	To EN 12354-2, 18 dB.
Accessories	Not required. Profyle flat. Guidance for specification option: Insulation strip made of adhesive and pre-cut polyethylene. 0.8–1.2 m per m² of floor surface. Stik HD. Guidance for specification option: High adhesion strength tape with superior ageing and weatherability performance. 0.1 m per m² of floor surface. Manufacturer guidance See manufacturer's literature for details.
Roll length	20 m.
