SXJ-0595 TruEtch Dual Strata Gradient Window Film

Name: SXJ-0595 TruEtch Dual Strata Gradient Window Film
Brand: Glass Films Europe
SKU: 9V9vxGosPFTUHA4bo8G9qC

Verified by manufacturer 1 day ago

Glass Films Europe

Product certifications:

BS EN 13501-1
Certificate type

Polyester frosted glass films with a dual fading gradient of blurred, tapering lines.

Jump to:

+44 (0)800 970 6366 Website

Application

Designed for application to interior glass, including single or double-pane, and exterior facing glass.

Description

Dual Strata Gradient is a polyester film with a simple frosted finish and a dual fading gradient of blurred, tapering lines that transition from white to clear.

Features and benefits:

For interior glass, including single or double-pane, and exterior facing glass.
Made from 50 µm-thick polyester.
Available in 1524 mm roll width.
Class B-s1, d0 to BS EN 13501-1:2018 flammability rating.
27% visible light reflection.
25% solar energy absorbed.
70% infrared transmission.
Supplied with a silicone coated liner and pressure-sensitive adhesive.

General information

Color	White Clear
Finish	Film
Material	Polyester
Shape	Rectangle
Length	Bespoke
Width	1524 mm
Height	0.05 mm
Warranty description	Five year Guidance for specification option: Subject to manufacturer's installation requirements.

Uniclass	Pr_25_57_51_60 Plastics window filmsPrimary
CAWS	L40/630 Manifestation L40/96 Manifestation L40/95 Window film L40/610 Window film

SKU Code	SXJ-0595

Specification data - Plastics window films

Classification data
Product reference	SXJ-0595 Dual Strata Gradient Window Film.
Purpose	Decorative. Privacy.
Fire performance	To BS EN 13501-1:2018, Class B-s1, d0.
Material	Polyester.
Colour	White to clear, tapering lines.
Dimensions	1524 mm roll.
Total shading coefficient	0.55.
Light reflectance	27%. Manufacturer guidance Visible light reflection.
Light transmission	49%. Manufacturer guidance Visible light transmission.
UV Transmission	2%.
Solar Energy Rejected	38%. Guidance for specification option: Solar energy absorbed of 25%.
Film thickness	50 μm.
Adhesive	Clear, pressure-sensitive.
Release Liner	Silicone coated.
