NBS Source
I'm a manufacturer

SXEG-1025 Stained Glass Doves - Dispersing Pattern Film for Glass

Verified by manufacturer 5 months ago

Glass Films Europe Third party certifications:
  • BS EN 13501-1

    BS EN 13501-1

    Certificate type

Glass film with a stained glass dove design.

Jump to:
+44 (0)800 970 6366 Website

Application

Designed for application to interior glass, single or double pane and exterior facing glass.

Description

SXEG-1025 Stained Glass Doves is a beautifully coloured, attractively designed PVC decorative stained glass film. This film simulates actual stained glass. Pattern repeats every ±27" down the roll length.


This film has a clear silicone release liner which protects the clear, pressure-sensitive adhesive, and is applied using the same tools and techniques for window films.


SOLYX & SIMGLAS Decorative Films must be installed by a Glass Films-approved window film installation company in order to retain the five-year manufacturer warranty. Please contact manufacturer to locate your nearest approved window film installer.

General information

Color

Blue

Green

Finish

Stained

Material

PVC

Length

Bespoke

Width

914 mm

Warranty description

Five year

Guidance for specification option:

Subject to manufacturer’s installation requirements, must be installed by a Glass Films-approved window film installation company. Consult manufacturer for details.

Uniclass

Pr_25_57_51_60 Plastics window filmsPrimary

CAWS

L40/96 Manifestation

L40/630 Manifestation

L40/610 Window film

L40/95 Window film

Product range

Stained Glass Films

Specification data - Plastics window films

Purpose

Decorative.

Privacy.

Solar control.

Ultra-violet (UV) protection.

Material

PVC.

Colour

Blue/ green.

Dimensions

Guidance for specification option:

Insert required length(s).

914 mm (36") wide as standard.

200 µm thick.

Fire performance

Manufacturer's standard.

Manufacturer guidance

Consult manufacturer for details.

Design

Stained glass dove design.

Guidance for specification option:

Beautifully coloured, attractively designed PVC decorative stained glass film simulating actual stained glass. Pattern repeats every ±27" down the roll length.

Light

Transmittance: 17%; reflectance: 28%.

Solar Control

Absorption: 42%; rejection: 49%.

Ultraviolet (UV) resistance

98%.

Adhesive

Clear, pressure-sensitive.

Guidance for specification option:

Supplied with a protective silicone release liner.

Sustainability data

Country of material origin

United States

Country of product manufacture

United States

Material

PVC

Manufacturing plant location

Expected Life

Ten year

Guidance for specification option:

Up to ten years.

Third party certifications

BS EN 13501-1

BS EN 13501-1

Solyx Vinyl Fire Certificate

Literature

Fire Ratings - Solyx & Simglas Decorative Glass Films

Fire Ratings - Solyx & Simglas Decorative Glass Films

SXEG-1025 Stained Glass Doves Specification Sheet

SXEG-1025 Stained Glass Doves Specification Sheet
