SX3-314 Acid Etch Window Film - Window Film
Verified by manufacturer 5 months ago
BS EN 13501-1
Certificate type
Acid etched window film.
Application
For application to interior and exterior glass.
Description
Acid etched window film that gives the uniform appearance of acid etched glass with a soft frosted appearance.
Features and benefits:
- For interior and exterior use.
- Flammability rating of class B-s1, d0 to BS EN 13501-1:2018.
- Made from 76 µm-thick vinyl.
- Supplied in fixed roll width of 54” (132 cm) and 60” (152 cm).
- Supplied with a paper liner and water-based acrylic, clear, pressure-sensitive adhesive.
This product meets ASTM E84 and is classified as Class A as defined in NFPA 101, Life Safety Code®.
General information
Color | Clear |
Finish | Etched |
Material | Vinyl |
Shape | Rectangle |
Width | 1371.6 mm 1524 mm |
Warranty description | Five year |
Uniclass | |
CAWS | L40/630 Manifestation L40/96 Manifestation L40/610 Window film L40/95 Window film |
Product range |
Specification data - Plastics window films
Purpose | Privacy. |
Material | Vinyl. |
Colour | Clear. |
Dimensions | 1371.6 mm.Guidance for specification option: Fixed roll width. 1524 mm.Guidance for specification option: Fixed roll width. |
Fire performance | To BS EN 13501-1:2018, Class B, s1, d0. |
Adhesive | Water-based acrylic, clear, pressure-sensitive. Guidance for specification option: Adhesive will whiten when installed with water solution and clears once cured.) The 45” width has a solvent acrylic adhesive with a plottable paper release liner. |
Film thickness | 76 µm. Guidance for specification option: 76 micron Vinyl. |
VisibleLightTransmittance | 78%. |
UV Transmission | 22%. Guidance for specification option: Infra-red transmission: 79%. |
Release Liner | Paper. |
Sustainability data
Country of material origin | United States |
Country of product manufacture | United States |
Material | Vinyl |
Manufacturing plant location | |
Expected Life | Ten year Guidance for specification option: Up to ten years. |
Third party certifications
BS EN 13501-1
Solyx Vinyl Fire Certificate
