SVK Fibre Cement Cladding

Verified by manufacturer 5 months ago

Puro Plus

Taylor Maxwell Variant:
Third party certifications:
  • BBA Agrément Certificate

    BBA Agrément Certificate

    Certificate type

Flat fibre – reinforced cement panels, used in back ventilated and drained rain-screen cladding systems.

Jump to:
0203 794 9377 Website

Application

External façade installations. Suitable for use on a new building, refurbishment or re-cladding project.

Description

Comprised of cement, PVA, cellulose fibres, aggregates and water, these cement cladding boards are available in standard sizes including 3050 x 1220 x 8 mm and 2520 x 1220 x 8 mm. There is also the option to create made-to-measure alternatives for individual projects. These flat fibre – reinforced cement panels, used in back ventilated and drained rain-screen cladding systems, provide a decorative and protective façade over timber-frame, steel frame or masonry external walls of new and existing buildings.


This strong and versatile range of cladding boards is suitable for use as an external façade panel and the naturally finished PuroPlus board has been tested to CWCT standards. During the production process, all product waste including the dust from sawing and polishing are incorporated into the next production process. Once a fibre cement panel reaches the end of its design life, it can be crushed and then used again in a new fibre cement production process. Cement fibre cladding panels combine seamlessly with several other façade materials, including facing bricks and stone and can be installed using a variety of fixing methods.


Features and benefits:

  • A2, s1-d0 fire rating in accordance with EN13501-01: 2018 (Section 7 BBA certificate number 22/5993).
  • European Technical Approval (ETA) covering Ornimat, Decoboard, Puro Plus and Colormat ranges.
  • Resistant to mould, rot and bacteria.
  • Easy to clean using clean water, with a mild detergent if required.
  • Supported by a 10-year manufacturer material and colour guarantee* Decoboard and Ornimat ranges.
  • Independently tested to CWCT standards – The Centre for Window and Cladding Technology.
  • Durability – under normal UK service conditions, the panels will have a service life of at least 30 years (see section 10 of BBA Certificate number 22/5993).

General information

Color

Other

Finish

Other

Material

Cement

Timber

Steel

Shape

Other

Length

2520 mm

3050 mm

Bespoke

Width

1220 mm

Bespoke

Height

8 mm

Bespoke

Warranty description

Ten year

Guidance for specification option:

Supported by a 10-year manufacturer material and colour guarantee* Decoboard and Ornimat ranges.

Uniclass

Ss_25_20_70_25 Drained and back-ventilated rainscreen cladding systemsPrimary

CAWS

H20/150 Sheet cladding (attached to metal support systems)

H20/10 Sheet cladding

H92/120 Rainscreen cladding

Specification data - Drained and back-ventilated rainscreen cladding systems

Thermal insulation

Guidance for specification option:

Consult manufacturer and insert requirements or omit.

Breather membrane

-

Material

Guidance for specification option:

Consult manufacturer and insert requirements or omit.

Fasteners

Guidance for specification option:

Consult manufacturer and insert requirements or omit.

Secondary support structure

Aluminium carrier rails.

Stainless steel carrier rails.

Timber carrier rails.

Cavity fire barriers

-

Horizontal

Guidance for specification option:

Consult manufacturer and insert requirements or omit.

Vertical

Guidance for specification option:

Consult manufacturer and insert requirements or omit.

Cladding panels

-

Material

Fibre-reinforced cement boards.

Panel joints

Open joints.

Reveals

Guidance for specification option:

Consult manufacturer and insert requirements or omit.

System accessories

Guidance for specification option:

Consult manufacturer and insert requirements or omit.

Panel Type

Puro Plus.

Fixing

Screws.

Guidance for specification option:

Panels can be attached with screws (wooden or metal) to the support structure.

Rivets.

Guidance for specification option:

Panels can be attached to the metal support structure using rivets.

Invisible mechanical fastening.

Guidance for specification option:

Panels can be installed using an invisible mechanical fastening system, where the backs of the panels are fitted with fastening points, in which panel hooks are placed with a tension-free anchor.

Surface finish

Natural.

Guidance for specification option:

Puro Plus façade panels are the naturally finished fibre cement material which is not given a coating. The finish is slightly sanded and alters in colour with different weather conditions to reveal different shades of natural grey.

Colour

Guidance for specification option:

Consult manufacturer for options and insert requirements.

Panel size

3050 x 1220 x 8 mm.

Guidance for specification option:

Standard size.

2520 x 1220 x 8 mm.

Guidance for specification option:

Standard size.

Made to measure.

Guidance for specification option:

Option for made-to-measure alternatives for individual projects. Consult manufacturer and insert requirements.

Density

1850 ± 150 kg·m‾³.

Manufacturer guidance

Average Density - Oven Dry (kg·m‾³).

Third party certifications

BBA Agrément Certificate

BBA Agrément Certificate

SVK Fibre Cement Cladding - 22/5993
