Application

  • Civic and public sector.
  • Schools and education.
  • Sport and leisure.

Description

Zaun Spectator Rails with Super Rebound 6 improves safety for both players and spectators. The players feel that the game is played at a higher level and that there is less likely to be any incursion on the pitch by eager fans. They are manufactured to the highest quality from strong tubular section and supplied with the Super 6 Rebound mesh infill – making them lightweight, robust and attractive. EPDM rubber inserts insulate the panels from the noise from impact during play, while stylish fixings hold the horizontal rails.

They can design any number of gates of any size into the pitch perimeter to allow maintenance equipment unfettered access to the pitch. The Football Association has made spectator rails a requirement for many Non-League clubs, but they are also suitable for areas such as skate parks, where spectators on the playing surface would pose a safety hazard.

Features and benefits:

  • Specifically designed to provide a demarcation area around sports pitches and MUGAs.
  • Provides protection for players and supporters during game play.
  • Designed to provide spectators better viewing.
  • Manufactured from strong tubular section.
  • Available with gates to suit.
  • Available either bolt down, in ground or on wall.

Applications:

  • Civic and public sector.
  • Schools and education.
  • Sport and leisure.

General information
Finish

Galvanized and polyester powder coated

Uniclass 2015 Metal mesh panel fencing systems (Ss_25_14_67_51)
Specification data
Product Reference

Super Rebound 6 Spectator Rail

Height

1.0–1.2 m, insert requirements.

Gates -
Pedestrian

Not required

Required

Single leaf, 1.2 m wide, or width to suit, consult manufacturer and insert requirements.

Vehicular

Not required

Required

Double leaf, 3.0 m wide, or width to suit, consult manufacturer and insert requirements.

Standard product features

Finish:

Galvanized and polyester powder coated.

Mesh:

Super Rebound 6 mesh comprising 66.6 x 50 mm with single 5 mm vertical wires at 50 mm centres and dual 6 mm horizontal wires at 66.6 mm centres.

Posts:

60 x 60 mm rectangular hollow section (RHS) posts, spaced at 2525 mm centres.

Post to panel fixing:

Panels fixed to posts with full height 40 x 5 mm clamp bar with bolt fixings at 200 mm centres with EPDM inserts. The full height clamp bars create a flush safe finish with the mesh ends behind the clamp bar.

Gates:

Framed in 50 x 50 mm RHS, with Zaun Super Rebound 6 mesh welded inside the frame, with slide latch. Gate supplied with rubber bump stop and two suitable gate posts. Vehicular access also supplied with drop bolts.
