Verified by manufacturer 4 months ago
BBA Agrément Certificate
Certificate type
BRE Certificate
Certificate type
European Technical Approval (ETA)
Certificate type
High performance structural thermal break plate.
Suitable for:
High performance structural thermal break plate.
Features and benefits:
Color | Yellow |
Finish | Smooth |
Material | Glass reinforced polyester |
Shape | Rectangle |
Length | Bespoke |
Width | Bespoke |
Height | Bespoke |
Warranty description | Lifetime |
Uniclass | |
CAWS | E40/440 Load transfer systems |
Product range |
Certification | SCI, BRE, BBA Passive House and NHBC. |
Material | Glass reinforced polyester. |
Dimensions | |
Thickness (maximum) | 5 mm.10 mm.15 mm.20 mm.25 mm. |
Compressive stress (maximum) | 312 MPa.Manufacturer guidanceCharacteristic: 312 MPa. Design: 250 MPa. |
Holes | Guidance for specification option: Insert requirement or drawing reference; contact manufacturer for information. |
Elastic modulus | 5178 MPa. |
Thermal Conductivity: | 0.187 W/m·K. |
Density | 1465 kg/m³. |
Water absorption | 0.14%. Manufacturer guidanceLong term creep: 20%. |
Dimensions | Manufacturer guidanceInsert requirement, available up to 2400 x 1200 mm. |
Contains Red List materials | No |
Country of material origin | Germany |
Country of product manufacture | United Kingdom |
Embodied carbonA1-A3 (production stage) as defined in BS EN 15804 | 0.43 kg CO₂ eq/kg Self declared |
Recyclability | fully reusable |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 0 % |
