StoSilent Direct, bonded acoustic ceiling and wall system

Verified by manufacturer 5 months ago

StoSilent Direct Climasan System

Sto Ltd Variant:

Acoustic ceiling and wall system.

Jump to:
+44 (0)330 024 2666 Website

Application

Suited for continuous, interior ceilings or walls without upstands. Can be applied to a wide range of substrates in the following locations:

  • Escape routes.
  • Corridors.
  • Staircases.
  • Meeting places.

Description

Acoustic ceiling and wall system, suitable for the creation of seamless solutions or exposed visible joints.


Features and benefits:

  • Requires no sub-construction.
  • Can be bonded directly to walls and ceilings. Pre-chamfered joints can be left in their original state, or filled prior to applying finishes.
  • Suitable for use in areas where room height is restricted.
  • High sound absorption due to pre-applied, porous texture surface and sandwich structure.
  • A wide range of over 800 colours is available (dependent on system type chosen).
  • StoSilent Direct Climasan System: With open joints. Can be coated directly for a dual-purpose ceiling.
  • Economical.
  • Low weight and high stiffness.
  • Seamless surfaces of up to 700 m² can be created without the need for a break in the system, as well as curves down to a radius of 5 m.
  • Minimal volatile organic compounds (VOCs), and formaldehyde- and carcinogen-free.
  • Not flammable.
  • Simple application.
  • Manufactured in accordance with ISO 14001 and ISO 9001.

Fixing:

StoSilent Coll MW mineral system adhesive. Colour: White. Consult manufacturer for details.

General information

Color

Other

Finish

Matt

Textured

Material

Mineral wool

Fibre

Shape

Rectangle

Length

Bespoke

Width

Bespoke

Height

Bespoke

Warranty description

Two year

Guidance for specification option:

Applicable to installations by registered installers.

In some circumstances the warranty period may be extended upon application prior to commencing installation; consult manufacturer for details.

Uniclass

Pr_35_93_13_80 Sound attenuator infill unitsPrimary

CAWS

K11/890 Board

K11/60 Board

Specification data - Sound attenuator infill units

Form

StoSilent Board MW 100.

Rigidity

Rigid.

Application

Ceiling mounting.

Wall mounting.

Material

Composite mineral wool fibre with a textured surface.

Acoustic performance

-

Purpose

Absorber.

Sound absorption

Up to 0.95 αW.

Fire performance

-

Reaction to fire

A2-s1, d0 (to EN 13501).

Dimensions

-

Size (length x width)

800 x 600 mm.

Thickness (overall)

46 mm.

66 mm.

Edges

Square.

Surface pattern

Solid.

Finish

Matt.

Colour

White.

Manufacturer guidance

  • For interior use. Odour-reducing, dead-matt emulsion paint, tested for harmful substances and wet-scrub resistance in accordance with EN 13300.
  • The chamfered board joints are left unfilled, and the boards are sprayed with an intermediate and top coat of StoColor Climasan paint, which breaks down any odours and harmful substances in the air. Recommended in StoColor Climasan white only – consult manufacturer for information.

Design

Insert drawing.

Insert reference.

Filler

Not applicable.

Weight

8 kg/m².

Third party certification:

QA Certificate; Natureplus®: 0602-0602-046-2; TÜV: Certificate: TM-10/160502-1.

Sustainability data

Contains Red List materials

No

Country of material origin

Germany

Country of product manufacture

Europe

Guidance for specification option:

Composite system manufactured across Europe.

Material

Mineral wool

Fibre

Recyclability

Separated mineral fibre recyclable

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

%

Guidance for specification option:

Unknown.
