Stonework

Application

Suitable for floor and wall tiling.

Description

A range of limestone effect wall and floor tiles. On request tiles can be tested to PTV BS7976-2. HSE surface roughness and NCS Colour values are also available upon request. All sizes shown are nominal.


General information

Finish

Matt

Polished

Stone

Bush hammered

Color

Black

Brown

Cream

Grey

Material

Porcelain

Shape

Rectangle

Square

Size

50 x 600 x 9.8 mm

50 x 600 x 10.8 mm

100 x 100 x 9.8 mm

100 x 100 x 10.8 mm

100 x 600 x 9.8 mm

Show more

Uniclass 2015

Pr_35_93_96_19 Ceramic tilesPrimary

CAWS

M40/5 Tiling to

M40/110 Tiling to

Specification data - Ceramic tiles Enhanced data

Colour

Landyn.

Arturo.

Korbin.

Makai.

Maxton.

Carina.

Elent.

Evess.

Dalix.

Lidia.

Finish

Refer to manufacturer's literature for available sizes and colours.

Matt R10.

Polished.

Stone R12 (A+B+C).

Bush hammered R11 (A+B+C).

Size

50 x 600 mm.

Selected colours: Carina and Elent, are not available in Polished 50 x 600 x 9.8mm.

100 x 100 mm.

100 x 600 mm.

100 x 1200 mm.

150 x 150 mm.

150 x 600 mm.

150 x 1200 mm.

300 x 300 mm.

300 x 600 mm.

300 x 900 mm.

300 x 1200 mm.

600 x 600 mm.

600 x 1200 mm.

900 x 900 mm.

Thickness

Refer to manufacturer's literature for availability of sizes and finishes.

9.8 mm.

10.8 mm.

Execution

To avoid lippage we recommend the use of self-levelling spacers.

Water absorption

To ISO 10545-3, ≤0.03%.

Flexural strength

To ISO 10545-4, 45 N/mm².

Abrasion resistance

To ISO 10545-6, 109 mm³.

Thermal expansion

To ISO 10545-8, 7x10-6ºC.

Thermal shock resistance

To ISO 10545-9.

Frost resistant and chemical resistant

Frost resistance to ISO 10545-12; Chemical resistance to ISO 10545-13.

Slip resistance

To DIN 51130 and DIN 51097.

Accessories

Not required.

Square top plinths.

Round top plinths.

Step threads.

Bullnose step threads; 300 x 300 mm.

Show more

Digital objects

Platform Compatible Version Certified to
Revit
-

1

2.1
IFC
-

1

2.1
Download now from NBS National BIM Library
