Steel Frame Slab - Insulation

Name: Steel Frame Slab - Insulation
Brand: ROCKWOOL Ltd
SKU: e614toPdJTosxqkRn897km

Verified by manufacturer 2 months ago

100 mm

ROCKWOOL Ltd

Third party certifications:

Quiet Mark Certification
Certificate type

Non-combustible thermal insulation designed specifically for steel frames.

Jump to:

BOS

+44 (0)1656 862621 Website

Application

Non-combustible thermal insulation designed specifically for steel frames.

Description

ROCKWOOL Steel Frame Slab delivers performance to meet and exceed thermal building regulations for external walls in steel frame buildings. Being made from stone wool means the highest Euroclass A1 non-combustible reaction to fire rating, as well as exceptional sound absorption properties.

The Steel Frame Slab delivers thermal performance at an optimal weight and features dimensions tailored for light gauge steel frame walls. The slab can significantly reduce outside sources of noise when used in an external wall. ROCKWOOL stone wool repels liquid water due to its fibre orientation and a water-repellent additive.

Features and benefits:

Low thermal conductivity of 0.034 W/m·K.
Euroclass A1 non-combustible (EN13501-1).
Open cell stone wool structure provides sound absorption.
Robust and durable stone wool slabs that maintain shape, fit and performance over time.
A sustainable, recyclable solution.
Produced using abundant, renewable volcanic rock.
CE marked to EN13162:2012+A1:2015.

Acoustic performance:

The Steel Frame Slab can significantly reduce outside sources of noise when used in an external wall.

Water resistance:

ROCKWOOL stone wool repels liquid water due to its fibre orientation and a water repellent additive.

General information

Material	Stonewool
Shape	Rectangle
Length	1200 mm
Width	600 mm
Height	100 mm 120 mm 150 mm

Uniclass	Pr_25_57_06_56 Mineral wool slab insulationPrimary
CAWS	K10/115 Metal stud partition system K10/125 Metal stud partition system K10/30 Metal stud K10/35 Wall lining system (metal framing) K10/165 Wall lining system (metal framing) K10/145 Wall lining system (metal studs) K10/155 Wall lining system (metal studs) K11/795 Wall lining on metal framing K11/796 Metal stud partition system P10/40 Insulation fitted betweenor to the face ofstuds

Specification data - Mineral wool slab insulation

General requirements	Insulation products generally.
Standard	To BS EN 13162, ISO 14001 and ISO 9001.
Thickness	100 mm. Other. Guidance for specification option: Non-standard thicknesses available on request, 50–200 mm. Consult manufacturer for details.
Edges	Square.
Thermal conductivity (maximum)	0.034 W/m·K.
Fire performance	Euroclass A1 non-combustible.

Vapour resistivity:	5.9 MN·s/g.
Size:	600 x 1200 mm. Guidance for specification option: Width x length.

Sustainability data

Country of material origin	United Kingdom
Country of product manufacture	United Kingdom
Material	Stonewool
Recyclability	Can be recycled Manufacturer guidance ROCKWOOL stone wool insulation is recyclable and can be transformed into new ROCKWOOL products. Please contact us for details of how we can work together to recycle waste ROCKWOOL stone wool material that may be generated during on-site installation.
