Description

A modular closed wall flexible storage system with a wide range of accessories and high performance characteristics. Its features make it equally successful as a 3 m high bulk storage unit and as a high density filing facility within the modern office. The intermediate uprights support the shelves in adjoining bays.

This design ensures that there are no sharp edges to the upright and no possibility of stock migrating from bay to bay or becoming trapped behind the posts. It also reduces the developed length of run.

The system is fully adjustable with none of the storage shelves bolted together. Each shelf can therefore be readily moved by untrained staff in 25 mm increments and the free standing dividers are infinitely adjustable. All shelves and interchangeable accessories simply snap onto the flush fitting shelf clips and can be easily added or relocated at any time after the initial installation.

Static Profile can be quickly converted to a mobile system to increase the density of the storage and steel or roller shutter doors can be added for security.

Able to carry loads of up to 500 kg per bay, depending upon the shelf pitch and each standard shelf is rated at 125 kg without reinforcement. Heavy duty shelves are also available.

The white smoke finish offers superb light reflecting qualities which make it ideal for narrow aisle shelving installations where lighting levels may be low. It is a colour which is complementary to any decor theme and it does not show up dust and therefore presents a clean appearance at all times.

General information
Size

Insert requirements or drawing reference.

Uniclass 2015
Pr_40_30_78_77 Shelf unitsPrimary
Specification data - Shelf units
Product Reference

Static Profile

Size

Insert requirements or drawing reference.

Accessories

None

Book supports

Duplex shelves

Heavy duty shelves

Lockers

Pull out cradles

Pull out drawers

Pull out shelves

Standard product features

Colour/ Finish:

White smoke polyester epoxy powder coated, RAL 9002.

Gauges:

  • Uprights: 1.0 mm.
  • Shelves: 0.9 mm.
  • Backsheet: 0.8 mm.
  • Backbrace: 3.0 mm.
  • Fixed divider: 0.8 mm.
  • Side support rail: 1.0 mm.
  • Free standing divider: 1.0 mm.
  • Shelf clip: 2.0 mm.

Product Options

Size:

Various options available consult manufacturer for details and insert requirements.
