SS Fire and Smoke Door Seal

Name: SS Fire and Smoke Door Seal
Brand: Lorient
SKU: 2mtrZDGipMtoj4SmXRZMBp

Verified by manufacturer 11 months ago

LP1004SS Fire and Smoke Door Seal

Product certifications:

Fire and smoke door seal with a polypropylene brush pile.

Jump to:

Application

For single and double leaf doors to protect against fire and smoke. Can be used with any architectural seals. Suitable for wheeled traffic.

Fire and smoke door seal with a polypropylene brush pile.

Features and benefits:

Door seal with a polypropylene brush pile, offering fire and smoke protection, with the added benefit of thermal containment.
Available in a choice of sizes to cover 30 and 60 minute applications, the SS seal also includes integral antimicrobial protection.
It includes very low frictional resistance for ease of door operation (Document M compliant) and meets smoke requirement BS 9999.
Suitable gap width, 3–4 mm.

Color	Black Manufacturer guidance Available in a range of standard colours, plus woodgrain finishes available to special order. Black brush as standard.
Material	PVC Intumescent
Shape	Rectangle
Length	1000 mm 2100 mm
Width	10 mm 15 mm 20 mm
Height	4 mm

Uniclass	Pr_35_90_33_22 Door and window weatherstrips and sealsPrimary
CAWS	L20/20 Wood flush doors L20/230 Wood flush doors L20/25 Wood panelled doors L20/250 Wood panelled doors L20/270 Wood doors L20/280 Doors L20/30 Wood doors L20/310 Wood door frames L20/330 Wood door frames L20/370 Door frames L20/410 Wood doorsets L20/420 Wood doorsets L20/430 Wood doorsets L20/480 Doorsets L20/52 Wood door frames L20/55 Doorsets L20/610 Roller shutters/ curtains

SKU Code	LP1004SS, LP1504SS, LP2004SS

Standard	To BS 476-31.1(smoke), to BS EN 1634-1 and BS 476-22 (fire) and to BS EN ISO 10140-2 (acoustics).
Third party certification	BBA Agrément Certificate, IFC and Certifire. Guidance for specification option: IFC - FRPP454. Certifire CF330 and CF341.
Functions	Fire and smoke seals.
Seal type	- Manufacturer guidance Insert requirement, available in a range of standard colours, plus woodgrain and metallic finishes, consult manufacturer for information.
Size	10 x 1000 mm. 10 x 2100 mm. Manufacturer guidance Other sizes are available to special order, consult manufacturer for information.
Materials	-
Seals	Polyvinyl chloride (PVC) encased sodium silicate and polypropylene brush pile.
Colour	Black.
