Description

Soap dispensers.

General information
Specification data
Product Reference

0302014 Vanity top or basin mounted soap dispenser

0302015 Vanity top or basin mounted soap dispenser

0302041 Lockable, retractable liquid soap dispenser

0302540 Lockable liquid soap dispenser

0302508 Lockable liquid soap dispenser

0302513 Lockable luxury liquid soap dispenser

0302514 Lockable luxury foam soap dispenser

0302521 Lockable push action liquid soap dispenser

0302532 Vanity or basin-mounted soap dispenser

0302525 Lockable push action liquid soap dispenser

Product Options

Product reference:

– 0302014 Vanity top or basin-mounted soap dispenser:

  • Construction: Chrome plated brass.
  • Dimensions: 70 mm high above mounting surface and 300 mm below, with 22 mm diameter push, 105 mm spout and 68 mm diameter reservoir.
  • Capacity: 500 ml, refillable from above or reservoir for a variety of liquid soaps and lotions.
  • Fixing: 23 mm (minimum) diameter hole in 45 mm (maximum) thickness worktop.
  • Construction: Chrome plated brass.
  • Dimensions: 95 mm high above worksurface and 300 mm below with 22 mm diameter push, 105 mm spout and 68 mm diameter reservoir.
  • Capacity: 500 ml, refillable from above or reservoir for a variety of liquid soaps.
  • Fixing: 23 mm (minimum) diameter hole in 45 mm (maximum) thickness worktop.

– 0302041 Lockable, retractable liquid soap dispenser:

  • Construction: Brushed stainless steel.
  • Size (h x w x d): 342 x 212 x 160 mm.
  • Soffit recess (w x d): 176 x 162 mm.
  • Weight: 2.3 kg.
  • Capacity: 500 ml refillable reservoir suitable for a variety of soaps and hand creams.
  • Single shot: 2 ml liquid soap.
  • Fixing: Includes fixing kit for soffit board installation.

– 0302540 Lockable liquid soap dispenser:

  • Construction: White ABS cover with blue translucent, viewing window, polypropylene backplate and refillable reservoir with lid.
  • Size (h x w x d): 250 x 115 x 115 mm.
  • Weight: 0.5 kg.
  • Capacity: 900 ml, lockable and refillable reservoir suitable for a variety of soaps and hand creams.
  • Single shot: 2 ml liquid soap.
  • Fixing: Includes fixing kit for hard wall installations.

– 0302508 Lockable liquid soap dispenser:

  • Construction: Satin stainless steel.
  • Size (h x w x d): 193 x 63 x 88 mm.
  • Weight: 1.2 kg.
  • Capacity: 250 ml, lockable and refillable reservoir suitable for a variety of soaps and hand creams.
  • Single shot: 2 ml liquid soap.
  • Fixing: Includes fixing kit for hard wall installations.

– 0302513 Lockable luxury liquid soap dispenser:

  • Construction: Lacquered stainless steel cover plate, light grey ABS cover and back plate with clear viewing capacity window, polypropylene refillable reservoir with lid.
  • Size (h x w x d): 255 x 130 x 120 mm.
  • Size (h x w x d): 255 x 130 x 120 mm.
  • Capacity: 900 ml, lockable and refillable reservoir suitable for flowable liquid soaps, gels and hand creams with viscosity of 1–20cps.
  • Single shot: 2 ml liquid soap.
  • Fixing: Includes fixing kit for hard wall installations.
  • Construction: Lacquered stainless steel cover plate, light grey ABS cover and backplate with clear viewing capacity window, polypropylene refillable reservoir with lid.
  • Size (h x w x d): 255 x 130 x 120mm.
  • Weight: 0.7 kg.
  • Capacity: 900 ml, lockable and refillable reservoir suitable for flowable liquid soaps with viscosity of 1–20cps.
  • Single shot: Foam, 20 ml; liquid, 0.6 ml.
  • Fixing: Includes fixing kit for hard wall installations.

– 0302521 Lockable push action liquid soap dispenser:

  • Construction: White epoxy polyester painted, Zintec corrosion resistant, carbon steel hinged cover with viewing window, giving easy access to the refillable polypropylene reservoir with lid.
  • Size (h x w x d): 255 x 130 x 120 mm.
  • Weight: 1.2 kg.
  • Capacity: 1.0 L suitable for a variety of flowable liquid soaps.
  • Single shot: 2 ml liquid soap.
  • Fixing: Includes fixing kit for hard wall installations.

– 0302532Vanity or basin-mounted soap dispenser:

  • Construction: Chrome plated brass.
  • Dimensions: 85 mm high above worksurface and 315mm below, with 44mm diameter push and 120 mm spout and 75 mm diameter reservoir.
  • Capacity: 1000 ml reservoir for a variety of liquid soaps and lotions, refillable from above.
  • Fixing: Into a 22 mm diameter hole in a maximum 45 mm thickness worktop.

– 0302525 Lockable push action liquid soap dispenser:

  • Construction: Brushed stainless steel hinged cover with viewing window, which gives easy access to the refillable polypropylene reservoir with lid.
  • Size (h x w x d): 255 x 130 x 120 mm.
  • Weight: 1.2 kg.
  • Capacity: 1.0 L suitable for a variety of flowable liquid soaps.
  • Single shot: 2 ml liquid soap.
  • Fixing: Includes fixing kit for hard wall installations.
